Huawei S1700 Series Switches

How to choose Huawei S1700 Series Switches

Huawei S1700 Series Switches are commonly sourced for enterprise access, aggregation, core and data center networks. Buyers should compare the complete configuration instead of relying on a family name or base price alone.

Compare port density, port speed, PoE budget, uplinks, switching capacity, stacking, airflow and software tier.
Confirm the exact model and suffix, included components, condition, warranty, lead time and destination requirements.
For installed-base expansion, verify software, interface, power, optics and management compatibility before ordering.

Recently Updated Huawei S1700 Series Switches

S1730S-S48P4S-A

Huawei CloudEngine S1730S-S48P4S-A PoE Access Switch

S1730S-S48P4S-A is the exact Huawei CloudEngine S1730S-S model represented by Huawei support and Info-Finder. Procurement must retain the complete -A identity and must not substitute the later -A1 or -A3 hardware revisions without a separate BOM and software-compatibility review.

HUAWEI Huawei S1700 Series Switches

S1700-8G-AC

Huawei S1700-8G-AC 8-Port Gigabit Ethernet Unmanaged Desktop Switch

Huawei S1700-8G-AC is a compact fanless switch with 8 x 10/100/1000Base-T electrical ports. Huawei lists 16 Gbit/s switching capacity and 12 Mpps forwarding performance.

HUAWEI Huawei S1700 Series Switches

S1700-8-AC

Huawei S1700-8-AC 8-Port 10/100 Ethernet Unmanaged Desktop Switch

Huawei S1700-8-AC is a compact fanless switch with 8 x 10/100Base-T electrical ports. Huawei lists 1.6 Gbit/s switching capacity and 1.2 Mpps forwarding performance.

HUAWEI Huawei S1700 Series Switches

S1700-28GR-4X

Huawei S1700-28GR-4X 24-Port Gigabit Switch with 4 x 10GE Optical Uplinks

Huawei S1700-28GR-4X is a fixed S1700 switch with 24 x 10/100/1000Base-T downlink ports and 4 x 10GBase-X optical uplinks. Huawei lists 168 Gbit/s switching capacity and 96 Mpps forwarding performance.

HUAWEI Huawei S1700 Series Switches

S1730S-S48T4S-A

Huawei CloudEngine S1730S-S48T4S-A 48GE Access Switch

S1730S-S48T4S-A is a non-PoE S1730S-S access switch with 48 GE copper ports, four GE optical uplinks and Huawei part number 98010902.

HUAWEI Huawei S1700 Series Switches

S1720-52GWR-PWR-4P-E

Huawei S1720-52GWR-PWR-4P-E 48-Port PoE+ Switch

Huawei S1720-52GWR-PWR-4P-E is a 48-port Gigabit PoE+ access switch with four 1000BASE-X uplinks, a 370 W built-in PoE budget and S1720GWR-E command-line management.

HUAWEI Huawei S1700 Series Switches

S1720-10GW-PWR-2P-E

Huawei S1720-10GW-PWR-2P-E 8-Port PoE+ Switch

Huawei S1720-10GW-PWR-2P-E combines eight Gigabit PoE+ ports, two 1000BASE-X uplinks and a 124 W PoE budget with the S1720GW-E command-line management option.

HUAWEI Huawei S1700 Series Switches

S1720-10GW-PWR-2P

Huawei S1720-10GW-PWR-2P 8-Port PoE+ Switch

Huawei S1720-10GW-PWR-2P is a fanless S1700 access switch with eight Gigabit PoE+ copper ports, two 1000BASE-X uplinks and a 124 W built-in PoE power budget.

HUAWEI Huawei S1700 Series Switches

S1730S-S48P4S-A

Condition: New Factory Sealed

Request current pricing

S1700-8G-AC

Condition: New Factory Sealed

Huawei S1700-8G-AC is a compact fanless switch with 8 x 10/100/1000Base-T electrical ports. Huawei lists 16 Gbit/s switching capacity and 12 Mpps forwarding performance.

Request current pricing

S1700-8-AC

Condition: New Factory Sealed

Huawei S1700-8-AC is a compact fanless switch with 8 x 10/100Base-T electrical ports. Huawei lists 1.6 Gbit/s switching capacity and 1.2 Mpps forwarding performance.

Request current pricing

S1700-28GR-4X

Condition: New Factory Sealed

Request current pricing

S1730S-S48T4S-A

Condition: New Factory Sealed

S1730S-S48T4S-A is a non-PoE S1730S-S access switch with 48 GE copper ports, four GE optical uplinks and Huawei part number 98010902.

Request current pricing

S1720-52GWR-PWR-4P-E

Condition: New Factory Sealed

Huawei S1720-52GWR-PWR-4P-E is a 48-port Gigabit PoE+ access switch with four 1000BASE-X uplinks, a 370 W built-in PoE budget and S1720GWR-E command-line management.

US$ 977.00

S1720-10GW-PWR-2P-E

Condition: New Factory Sealed

Huawei S1720-10GW-PWR-2P-E combines eight Gigabit PoE+ ports, two 1000BASE-X uplinks and a 124 W PoE budget with the S1720GW-E command-line management option.

US$ 400.00

S1720-10GW-PWR-2P

Condition: New Factory Sealed

Huawei S1720-10GW-PWR-2P is a fanless S1700 access switch with eight Gigabit PoE+ copper ports, two 1000BASE-X uplinks and a 124 W built-in PoE power budget.

US$ 411.00

S1730S-L8T-A

Condition: New Factory Sealed

S1730S-L8T-A is Huawei part 98010873: eight 10/100/1000BASE-T ports, no PoE, an external power adapter, fanless cooling and a maximum 5 W draw at full traffic.

Request current pricing

S1730S-S1

Condition: New Factory Sealed

S1730S-S1 is a Huawei CloudEngine managed campus-switch subseries. It does not identify one port layout; hardware suffix and supported software release must be selected together.

Request current pricing

S1730S-L

Condition: New Factory Sealed

S1730S-L is Huawei's unmanaged FutureMatrix switch family for SOHO and small-site access. It is a series selector, not a complete hardware order; the full suffix determines ports, speed, PoE, uplinks and power.

Request current pricing

S1720-52GWR-4X

Condition: New Factory Sealed

S1720-52GWR-4X is a Huawei S1720 switch with 48 x 10/100/1000BASE-T electrical downlinks, 4 x 10GBASE-X optical uplinks, and 336Gbps switching capacity and 132Mpps forwarding performance. Non-PWR model; do not assume PoE output.

Request current pricing

S1720-52GFR-PWR-4P

Condition: New Factory Sealed

S1720-52GFR-PWR-4P is a Huawei S1720 switch with 48 x 10/100/1000BASE-T electrical downlinks, 4 x 1000BASE-X optical uplinks, and 336Gbps switching capacity and 78Mpps forwarding performance. PWR variant for powered-edge designs; verify the exact PoE standard and budget from the order documentation.

Request current pricing

S1720-52GFR-4P

Condition: New Factory Sealed

S1720-52GFR-4P is a Huawei S1720 switch with 48 x 10/100/1000BASE-T electrical downlinks, 4 x 1000BASE-X optical uplinks, and 336Gbps switching capacity and 78Mpps forwarding performance. Non-PWR model; do not assume PoE output.

Request current pricing

S1720-28GFR-PWR-4P

Condition: New Factory Sealed

S1720-28GFR-PWR-4P is a Huawei S1720 switch with 24 x 10/100/1000BASE-T electrical downlinks, 4 x 1000BASE-X optical uplinks, and 68Gbps switching capacity and 42Mpps forwarding performance. PWR variant for powered-edge designs; verify the exact PoE standard and budget from the order documentation.

Request current pricing

S1720-28GFR-4P

Condition: New Factory Sealed

S1720-28GFR-4P is a Huawei S1720 switch with 24 x 10/100/1000BASE-T electrical downlinks, 4 x 1000BASE-X optical uplinks, and 68Gbps switching capacity and 42Mpps forwarding performance. Non-PWR model; do not assume PoE output.

Request current pricing

S1700-16R

Condition: New Factory Sealed

S1700-16R is a Huawei S1700 unmanaged switch with sixteen 10/100BASE-T electrical ports, 3.2Gbps switching capacity and 2.4Mpps forwarding performance. It has no PoE or separate uplink port in the published configuration.

Request current pricing

S1720X-32XWR-E

Condition: New Factory Sealed

Huawei S1720X-32XWR-E is part number 98010761, sharing the documented non-PoE hardware structure of S1720X-32XWR while retaining a separate exact ordering identity.

US$ 1,178.00

S1720X-32XWR

Condition: New Factory Sealed

Huawei S1720X-32XWR is a non-PoE S1720 switch with built-in AC power, three fixed fans and no stack-port support; Huawei maps it to V200R019C10.

US$ 1,178.00

S1730S-L4P4T-A

Condition: New Factory Sealed

S1730S-L4P4T-A combines four PoE+ 10/100/1000BASE-T ports with four non-PoE 10/100/1000BASE-T ports in a fanless chassis with a built-in AC power module.

US$ 190.00
