ASR1001X-2.5G-K9 Cisco ASR 1000 Series Router
- 763 412 7282
- +86 010 69614620
ASR1001X-2.5G-K9 Overview
ASR1001X-2.5G-K9 is a CISCO enterprise router listed by YYST Global for WAN edge routing, branch connectivity, spare replacement and enterprise routing upgrades. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: ASR1001X-2.5G-K9 Cisco ASR 1000 Series Router. Category: Cisco Router ASR 1000. Condition: New Factory Sealed.
ASR1001X-2.5G-K9 Specification
| Datasheet series | Cisco ASR 1000 Series Aggregation Services Routers |
| Exact model | ASR1001X-2.5G-K9 |
| Official datasheet | Cisco ASR 1000 Series official product page |
| Parameter | Specification / Value |
|---|---|
| Model Number | Cisco ASR1001X-2.5G-K9 |
| Product Type | Aggregation Services Router |
| Series | Cisco ASR 1000 Series |
| Processor Architecture | Cisco QuantumFlow Processor (QFP) multi-core architecture |
| System Throughput | 2.5 Gbps (base license), scalable to 5, 10, or 20 Gbps (via software license) |
| Form Factor | 1 Rack Unit (1U) |
| Rack Mountable | Yes |
| Integrated Network Ports | 6 × 10/100/1000 Mbps Ethernet ports (RJ-45/SFP combo) |
| 10-Gigabit Ethernet Ports | 2 × 10GE SFP+ ports |
| Shared Port Adapter (SPA) Slots | 1 × SPA slot (for modular interface expansion) |
| Embedded Services Processor (ESP) | Integrated (hardware-based data forwarding engine) |
| Route Processor (RP) | Integrated dual-core CPU route processor |
| Memory (Default DRAM) | 8 GB |
| Maximum DRAM | 16 GB |
| Default Flash Memory | 8 GB |
| Maximum Flash Memory | 32 GB |
| USB Ports | 1 × USB Type A (storage), 1 × mini-USB console |
| Console / Auxiliary Ports | 1 × RJ-45 console, 1 × RJ-45 auxiliary |
| Power Supply Options | Dual redundant, hot-swappable AC or DC power supplies |
| Typical Power Consumption | Approximately 250 W |
| Maximum Power Consumption | Up to 400 W (fully loaded) |
| Cooling System | Front-to-back airflow with modular fan tray |
| Dimensions (H × W × D) | 43.9 × 438.15 × 482.6 mm (1.73 × 17.25 × 19 inches) |
| Weight | Approximately 10.9 kg (24 lbs) |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Storage Temperature | -40 °C to 70 °C (-40 °F to 158 °F) |
| Operating Humidity | 10% – 85% (non-condensing) |
| Forwarding Performance | Up to 20 million packets per second |
| Routing Protocols Supported | Static, RIP, OSPF, EIGRP, IS-IS, BGP, MPLS, VRF, IPv4/IPv6 dual stack |
| Security Features | IPsec VPN, SSL VPN, Zone-Based Firewall, Control Plane Protection, NAT, Access Control Lists (ACLs) |
| QoS Capabilities | Hierarchical QoS (HQoS), traffic classification, policing, shaping, prioritization |
| Virtualization Support | Cisco IOS XE service containers, NFVIS, and SD-WAN features |
| High Availability Features | Stateful Switchover (SSO), Nonstop Forwarding (NSF), In-Service Software Upgrade (ISSU) |
| Management Interfaces | CLI, Web UI, SNMP v1/v2/v3, NetFlow, NETCONF, RESTCONF, SSH, HTTPS |
| Operating System | Cisco IOS XE |
| Licensing Model | Software-based throughput and feature activation (IP Base, Advanced IP Services, Advanced Enterprise Services) |
| Typical Use Cases | Enterprise WAN aggregation, branch or regional edge routing, MPLS PE router, secure SD-WAN edge device |
ASR1001X-2.5G-K9 Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | Free CCIE Expert Technical Support |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
ASR1001X-2.5G-K9 FAQ
What is ASR1001X-2.5G-K9?
ASR1001X-2.5G-K9 Cisco ASR 1000 Series Router is a CISCO Router ASR 1000 product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What system throughput is listed for ASR1001X-2.5G-K9?
For ASR1001X-2.5G-K9, the manufacturer specification lists system throughput as 2.5 Gbps (base license), scalable to 5, 10, or 20 Gbps (via software license).
What interfaces and ports does ASR1001X-2.5G-K9 provide?
For ASR1001X-2.5G-K9, the manufacturer specification lists integrated network ports as 6 × 10/100/1000 Mbps Ethernet ports (RJ-45/SFP combo).
Is ASR1001X-2.5G-K9 available from YYST Global?
ASR1001X-2.5G-K9 is in stock at YYST Global. Contact the sales team to confirm the required quantity, exact configuration, delivery destination and current lead time before ordering.
What is the price of ASR1001X-2.5G-K9?
The current reference price for ASR1001X-2.5G-K9 is US$ 1,800.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
