ARUBA JW633A HPE 7005 Series Mobility Controllers
- 763 412 7282
- +86 010 69614620
JW633A Buying Guide
JW633A HPE Aruba 7005 (RW) 4-port 10/100/1000BASE-T 16 AP Controller is listed by YYST Global for buyers looking for ARUBA HPE Aruba 7005 Series Mobility Controllers. JW633A ARUBA wireless networking hardware for campus WLAN projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 1,105.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: JW633A
- Brand: ARUBA
- Category: HPE Aruba 7005 Series Mobility Controllers
- Condition: New Factory Sealed
- Reference price: US$ 1,105.00
JW633A Overview
JW633A is a ARUBA wireless networking hardware listed by YYST Global for campus WLAN expansion, controller replacement, access point rollout and wireless refresh projects. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: JW633A HPE Aruba 7005 (RW) 4-port 10/100/1000BASE-T 16 AP Controller. Category: HPE Aruba 7005 Series Mobility Controllers. Condition: New Factory Sealed.
JW633A Specification
| Datasheet series | HPE Aruba Mobility Controllers |
| Exact model | JW633A |
| Product role | Wireless mobility controller or gateway; confirm AP capacity, license, interface, redundancy and software version requirements |
| Management check | Confirm Aruba Central, controller, AirWave or local management requirements |
| Procurement check | Confirm country domain, accessories, license/support term and project compatibility |
| Procurement validation | Confirm exact part number, condition, licenses, accessories, power/airflow option, warranty, stock and lead time before purchase |
| Official datasheet | HPE Aruba gateways and controllers official product page |
| Physical specifications | |
| Dimensions (H x W x D) | 4.1 x 20 x 20 cm (1.6 x 7.9 x 7.9 in) |
| Weight | 0.92 kg (2.03 lb) |
| MTBF (hours, @ 25C) | 323,896 |
| Environmental specifications | |
| Acoustic noise1 | 0 dBA (fanless) |
| Maximum power consumption | 16.6 W (with USB) |
| Power source | PoE or 12v - 30 W |
| Operating temperature | 0° C to 40° C |
| Storage temperature | -40° C to 70° C |
| Humidity/storage humidity | 5% to 95%, NC |
| Operating altitude | 10,000 feet |
| Regulatory and safety compliance | |
| Safety certifications | UL 60950-1 Second Edition CAN/CSA-C22.2 No. 60950-1 Second Edition EN 60950-1 Second Edition EN 60950:2005 IEC 60950-1 Second Edition NOM (obtained by partners and distributors) |
| Electromagnetic emissions certifications | FCC Part 15 Class B CE AS/NZS CISPR22 Class B CISPR22 Class A (7010, 7024, 7030), Class B (7005) EN55022 Class A (7010, 7024, 7030), Class B (7005) ICES-003 Class A (7010, 7024, 7030), Class B (7005) VCCI Class A (7010, 7024, 7030), Class B (7005) EN61000-3-2 EN61000-3-3 EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4- 6, EN 61000- 4-8, EN 61000-4-11, AS/NZS 3548 KN22 Class B KCC CNS13438 Class B EN55024/CISPR24 KN24 Industry Canada Class B CE mark, cTUVus, CB, C-tick, Anatel, NOM, MIC |
| Telco | Common Language Equipment Identifier (CLEI) Code |
| Regulatory SKU information | ARCN01014(7005), ARCN0103(7010), ARCN7024(7024), ARCN7030(7030) |
| Minimum ArubaOS Release | 7005, AOS 6.4.1.0; 7010, AOS 6.4.1.0; 7024, AOS 6.4.3.0; 7030, AOS 6.4.1.0 |
| Performance and capacity | |
| Maximum campus AP licenses | 16 |
| Maximum concurrent users/devices | 1,024 |
| Maximum VLANs | 4,096 |
| Active firewall sessions | 16K |
| Concurrent GRE tunnels | 256 |
| Concurrent IPsec sessions | 1,024 |
| Concurrent tunneled ports | 1,024 |
| Firewall throughput | 4 Gb/s |
| Wired bridged throughput | 4 Gb/s |
| Encrypted throughput (3DES) | 1.2 Gb/s |
| Encrypted throughput AES-CBC-256 | 1.3 Gb/s |
| Encrypted throughput (AES-CCM) | 2.0 Gb/s |
| Encrypted throughput AESGCM-256 | 1.7 Gb/s |
| Interfaces and indicators | |
| Form factor/footprint | Desktop/ fanless |
| Auto-negotiating 10/100/1000BASE-T | 4 |
| Gigabit Ethernet ports (GBIC or SFP) | N/A |
| 10G Ports (10G or 1G supported) | N/A |
| USB 2.0 | 1 |
| Management/status LEDs | Yes |
| LINK/ACT and status LEDs | Yes |
| LCD panel and navigation buttons | No |
| Console port | Mini USB/RJ-45 |
| Out-of-band management port | No |
JW633A Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | 100% Money Back Guarantee |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
JW633A FAQ
What is JW633A?
JW633A HPE Aruba 7005 (RW) 4-port 10/100/1000BASE-T 16 AP Controller is a ARUBA HPE Aruba 7005 Series Mobility Controllers product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the datasheet series of JW633A?
The listed datasheet series for JW633A is HPE Aruba Mobility Controllers. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the exact model of JW633A?
The listed exact model for JW633A is JW633A. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is JW633A available from YYST Global?
YYST Global can help check availability, lead time and configuration for JW633A. Contact the sales team before ordering to confirm current stock.
What is the price of JW633A?
The current reference price for JW633A is US$ 1,105.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
