RUCKUS 901-R730-WW00 R730 Access Point
- 763 412 7282
- +86 010 69614620
901-R730-WW00 Buying Guide
901-R730-WW00 RUCKUS R730 Indoor 802.11ax 8x8:8 Wi-Fi Access Point is listed by YYST Global for buyers looking for RUCKUS RUCKUS R730 Access Point. 901-R730-WW00 RUCKUS wireless networking hardware for campus WLAN projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 832.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: 901-R730-WW00
- Brand: RUCKUS
- Category: RUCKUS R730 Access Point
- Condition: New Factory Sealed
- Reference price: US$ 832.00
901-R730-WW00 Overview
901-R730-WW00 is a RUCKUS wireless networking hardware listed by YYST Global for campus WLAN expansion, controller replacement, access point rollout and wireless refresh projects. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: 901-R730-WW00 RUCKUS R730 Indoor 802.11ax 8x8:8 Wi-Fi Access Point. Category: RUCKUS R730 Access Point. Condition: New Factory Sealed.
901-R730-WW00 Specification
| Datasheet series | Ruckus Wireless Access Points |
| Exact model | 901-R730-WW00 |
| Product role | Enterprise wireless access point; confirm antenna, radio generation, controller/cloud compatibility and mounting kit |
| Management check | Confirm SmartZone, Unleashed, Cloudpath or Ruckus Cloud compatibility as applicable |
| Deployment check | Confirm power, accessories, country domain, firmware and warranty terms before order |
| Procurement validation | Confirm exact part number, condition, licenses, accessories, power/airflow option, warranty, stock and lead time before purchase |
| Official datasheet | Ruckus wireless access points official product page |
| 901-R730-WW00 | R730 dual-band (5GHz and 2.4GHz concurrent) 802.11ax wireless access point, Ultra-High Density performance, 12 spatial streams, adaptive antennas, PoE support. Includes adjustable acoustic drop ceiling bracket. Two Ethernet ports with 1GbE and 5Gbe. Does not include power adaptor | ||||
| Wi-Fi Standards | IEEE 802.11a/b/g/n/ac/ax | ||||
| Supported Rates | · 802.11ax: 4 to 4800 Mbps · 802.11ac: 6.5 to 3467 Mbps · 802.11n: 6.5 to 600 Mbps · 802.11a/g: 6 to 54 Mbps · 802.11b: 1 to 11 Mbps |
||||
| Supported Channels | 2.4GHz: 1-13 5GHz: 36-64, 100-144, 149-165 |
||||
| MIMO | 8x8 MU-MIMO 8x8 SU-MIMO |
||||
| Spatial Streams | 8 MU-MIMO 8 SU-MIMO |
||||
| Radio Chains and Streams | 8x8:8 | ||||
| Modulation | OFDMA (up to 1024-QAM) | ||||
| Channelization | 20, 40, 80 MHz | ||||
| Security | WPA-PSK, WPA-TKIP, WPA2 AES, 802.11i, Dynamic PSK WIPS/WIDS |
||||
| Other Wi-Fi Features | · WMM, Power Save, TxBF, LDPC, STBC, 802.11r/k/vHotspot · Hotspot 2.0 · Captive Portal · WISPr |
||||
| Antenna Type | BeamFlex+ adaptive antennas with 4000+ unique antenna patterns Horizontal and Vertical polarization (PD-MRC) |
||||
| Antenna Gain (max) | Up to 2dBi | ||||
| Simultaneous VoIP Clients | Up to 60 per AP | ||||
| Frequency Bands | 2.4–2.484 GHz 5.17–5.33 GHz 5.49–5.71 GHz 5.735–5.835 GHz |
||||
| Peak PHY Rates | 2.4 GHz: 1.148 Gbps 5 GHz: 4.8 Gbps |
||||
| Client Capacity | Up to 1024 clients per AP | ||||
| SSID | Up to 16 per radio | ||||
| Antenna Optimization | BeamFlex+ PD-MRC |
||||
| Wi-Fi Channel Management | · ChannelFly | ||||
| Client Density Management | Band Balancing Client Load Balancing Airtime Fairness Airtime-based WLAN Prioritization |
||||
| Queuing & Scheduling | SmartCast | ||||
| Mobility | SmartRoam | ||||
| Diagnostic Tools | Spectrum Analysis SpeedFlex |
||||
| High Density Deployments (RF Innovations) | · Perpacket Adaptive Power · Adaptive Wi-Fi Cell Size · Transient Client Management · Airtime Decongestion |
||||
| Controller Platform Support | · SmartZone (SZ3.6.2 and SZ v5.1.1) · ZD (ZD10.1.2) · Standalone · Please note: R730 is *not* supported on SZ v5.0.x and SZ v5.1.0 · Cloud |
||||
| Mesh | SmartMesh ™ wireless meshing technology | ||||
| IP | IPv4, IPv6 | ||||
| VLAN | · 802.1Q · BSSID-based (16 BSSIDs / radio) · Port-based · Dynamic, per user based on RADIUS |
||||
| 802.1x | · Wired & wireless · Authenticator & Supplicant |
||||
| Tunnel | RUCKUSGRE, SoftGRE | ||||
| Policy Management Tools | · Application Recognition and Control · Access Control Lists · Device Fingerprinting |
||||
| IoT Capbale | Yes | ||||
| IoT | BLE, Zigbee | ||||
| Ethernet | · 1x 1/2.5/5 Gbps port, RJ-45 · 1x 10/100/1000 Mbps port, RJ-45 |
||||
| USB | 1 USB 2.0 port, Type A | ||||
| Physical Size (L x W x H) | · 22.19 x 24.96 x 6 cm · 8.74 x 9.83 x 2.36 in |
||||
| Weight | · 1.53 kg · 3.37 lbs |
||||
| Mounting | Wall, acoustic ceiling, desk Secure bracket (sold separately) |
||||
| Physical Security | · Hidden latching mechanism | ||||
| Operating Temperature | · -0C (32F) to 50°C (122°F) | ||||
| Operating Humidity | Up to 95%, non-condensing | ||||
| Wi-Fi Alliance | · Wi-Fi CERTIFIED™ a, b, g, n, ac · Passpoint® · Vantage |
||||
| Standards Compliance | EN 60950-1 Safety EN 60601-1-2 Medical EN 61000-4-2/3/5 Immunity EN 50121-1 Railway EMC EN 50121-4 Railway Immunity IEC 61373 Railway Shock & Vibration UL 2043 Plenum EN 62311 Human Safety/RF Exposure WEEE & RoHS ISTA 2A Transportation |
||||
| Location Based Services | SPoT | ||||
| Network Analytics | SmartCell Insight (SCI) | ||||
| Security and Policy | Cloudpath | ||||
| IoT | RUCKUS IoT Suite | ||||
| OPTIONAL ACCESSORIES | |||||
| 902-0180-XX00 | PoE Injector (60W) | ||||
| 902-1170-XX00 | Power Supply (48V, 0.75A, 36W) | ||||
| 902-0120-0000 | Spare, Accessory Mounting Bracket | ||||
| 2.4GHZ RECEIVE SENSITIVITY | |||||||
| HT20 | HT40 | VHT20 | VHT40 | ||||
| MCS0 | MCS7 | MCS0 | MCS7 | MCS0 | MCS7 | MCS0 | MCS7 |
| -91 | -73 | -88 | -70 | -91 | -73 | -88 | -70 |
| HE20 | HE40 | ||||||
| MCS0 | MCS7 | MCS9 | MCS11 | MCS0 | MCS7 | MCS9 | MCS11 |
| -91 | -73 | -68 | -62 | -88 | -70 | -65 | -59 |
| 5GHZ RECEIVE SENSITIVITY | |||||||||||
| VHT20 | VHT40 | VHT80 | |||||||||
| MCS0 | MCS7 | MCS8 | MCS9 | MCS0 | MCS7 | MCS8 | MCS9 | MCS0 | MCS7 | MCS8 | MCS9 |
| -91 | -72 | -69 | — | -88 | -69 | — | -65 | -85 | -66 | — | -62 |
| HE20 | HE40 | HE80 | |||||||||
| MCS0 | MCS7 | MCS9 | MCS11 | MCS0 | MCS7 | MCS9 | MCS11 | MCS0 | MCS7 | MCS9 | MCS11 |
| -91 | -72 | -68 | -62 | -88 | -69 | -65 | -59 | -85 | -66 | -62 | -56 |
| 2.4GHZ TX POWER TARGET (PER CHAIN) | |||||
| Rate | Pout (dBm) - Full Power | Pout (dBm) - 802.3at | |||
| MCS0 HT20 | 20 | 20 | |||
| MCS7 HT20 | 16 | 16 | |||
| MCS8 VHT20 | 15 | 15 | |||
| MCS9 VHT40 | 14 | 14 | |||
| MCS11 HE40 | 12 | 12 | |||
| 5GHZ TX POWER TARGET (PER CHAIN) | |||||
| Rate | Pout (dBm) - Full Power | Pout (dBm) - 802.3at | |||
| MCS0 VHT20 | 22 | 22 | |||
| MCS7 VHT40, VHT80 | 16.5 | 16.5 | |||
| MCS9 VHT40, VHT80 | 15 | 15 | |||
| MCS11 HE20, HE40, HE80 | 12.5 | 12.5 | |||
| POWER CONSUMPTION | |||||
| Mode | Power Consumption | System Configuration | Wi-Fi Radios | ||
| DC Power, PoH, uPoE (Idle) |
16.1W | · 5Gbps & 1Gbps Ethernet enabled · USB Enabled (3W) · Zigbee/BLE Enabled (0.5W) |
2.4GHz (4x4) enabled 5GHz (8x8) enabled (no clients associated) |
||
| DC Power, PoH, uPoE (Max) |
31.0W | · 5Gbps & 1Gbps Ethernet enabled · USB Enabled (3W) · Zigbee/BLE Enabled (0.5W) |
2.4GHz (4x4) Tx 20 dBm 5GHz (8x8) Tx 22 dBm |
||
| 802.3at (Max) | 23.8W | · 5Gbps & 1Gbps Ethernet enabled · USB Enabled (3W) · Zigbee/BLE Disabled |
2.4GHz (4x4) Tx 20 dBm 5GHz (4x4) Tx 22 dBm |
||
| 802.3af (Not recommended) | 12.4W | · 5Gbps & 1Gbps Ethernet enabled · USB disabled · Zigbee/BLE Disabled |
2.4GHz disabled 5GHz disabled |
||
901-R730-WW00 Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | 100% Money Back Guarantee |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
Firmware Download
901-R730-WW00 FAQ
What is 901-R730-WW00?
901-R730-WW00 RUCKUS R730 Indoor 802.11ax 8x8:8 Wi-Fi Access Point is a RUCKUS RUCKUS R730 Access Point product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the datasheet series of 901-R730-WW00?
The listed datasheet series for 901-R730-WW00 is Ruckus Wireless Access Points. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the exact model of 901-R730-WW00?
The listed exact model for 901-R730-WW00 is 901-R730-WW00. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is 901-R730-WW00 available from YYST Global?
YYST Global can help check availability, lead time and configuration for 901-R730-WW00. Contact the sales team before ordering to confirm current stock.
What is the price of 901-R730-WW00?
The current reference price for 901-R730-WW00 is US$ 832.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
