H3C EWP-WA5530-FIT Three-Radio 802.11ac Wave 2 Access Point
- 763 412 7282
- +86 010 69614620
EWP-WA5530-FIT Overview
Three radios do not mean three frequency bands
This model uses the 2.4 GHz and 5 GHz bands. It is not a 6 GHz access point. H3C lists internal antennas, two Gigabit Ethernet connections, one console port and 802.3at-compatible PoE, with 54 V DC as the local power option.
Plan the wired and power installation
For a replacement, record the existing switch ports, cable runs and power source. Request verification of the intended power arrangement and any required adapter before approving the order. Do not treat a combined radio-rate figure as application throughput or assume that two Ethernet connectors each support a multi-gigabit link.
Match the supplied article to the WLAN
Quote the full EWP-WA5530-FIT article and the installed controller release. Ask for controller compatibility, regional configuration, mounting items and entitlement requirements to be checked. WA5530-SI and WA5530-LI are different variants; a family-name match alone is insufficient for substitution.
The evidence linked here describes the WA5530 model; the precise supplied regional order code, condition and accessories remain quotation checks. H3C WA5530 model specifications.
EWP-WA5530-FIT Specification
| Existing listing | EWP-WA5530-FIT |
|---|---|
| Documented model | WA5530 |
| Wireless generation | 802.11ac Wave 2 |
| Radio / band distinction | Three radios; 2.4 GHz and 5 GHz bands |
| Ethernet | Two Gigabit ports |
| Power options | 802.3at-compatible PoE; 54 V DC local input |
| Antennas | Internal |
| Variant check | Not WA5530-SI or WA5530-LI |
EWP-WA5530-FIT Warranty
 | Product Quotation |  | Condition and Packaging |
 | Return Eligibility |  | Returns and Replacement |
 | Shipping Arrangements |  | Warranty Terms |
EWP-WA5530-FIT FAQ
What is EWP-WA5530-FIT?
H3C EWP-WA5530-FIT Three-Radio 802.11ac Wave 2 Access Point is a H3C Wireless product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What wireless generation is listed for EWP-WA5530-FIT?
For EWP-WA5530-FIT, the manufacturer specification lists wireless generation as 802.11ac Wave 2.
What radio / band distinction is listed for EWP-WA5530-FIT?
For EWP-WA5530-FIT, the manufacturer specification lists radio / band distinction as Three radios; 2.4 GHz and 5 GHz bands.
What interfaces and ports does EWP-WA5530-FIT provide?
For EWP-WA5530-FIT, the manufacturer specification lists ethernet as Two Gigabit ports.
Is EWP-WA5530-FIT available from YYST Global?
Contact YYST Global to confirm availability for EWP-WA5530-FIT, the required quantity, exact configuration, delivery destination and current lead time before ordering. A product listing does not confirm current inventory.
