ARUBA JW649A HPE 7200 Series Mobility Controllers
- 763 412 7282
- +86 010 69614620
JW649A Buying Guide
JW649A Aruba 7220DC (RW) 4p 10GBase-X 2p Dual Pers 350W DC Pwr Cntrlr is listed by YYST Global for buyers looking for ARUBA HPE Aruba 7200 Series Mobility Controllers . JW649A ARUBA wireless networking hardware for campus WLAN projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 200.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: JW649A
- Brand: ARUBA
- Category: HPE Aruba 7200 Series Mobility Controllers
- Condition: New Factory Sealed
- Reference price: US$ 200.00
JW649A Overview
JW649A is a ARUBA wireless networking hardware listed by YYST Global for campus WLAN expansion, controller replacement, access point rollout and wireless refresh projects. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: JW649A Aruba 7220DC (RW) 4p 10GBase-X 2p Dual Pers 350W DC Pwr Cntrlr. Category: HPE Aruba 7200 Series Mobility Controllers. Condition: New Factory Sealed.
JW649A Specification
| Datasheet series | HPE Aruba Mobility Controllers |
| Exact model | JW649A |
| Product role | Wireless mobility controller or gateway; confirm AP capacity, license, interface, redundancy and software version requirements |
| Management check | Confirm Aruba Central, controller, AirWave or local management requirements |
| Procurement check | Confirm country domain, accessories, license/support term and project compatibility |
| Procurement validation | Confirm exact part number, condition, licenses, accessories, power/airflow option, warranty, stock and lead time before purchase |
| Official datasheet | HPE Aruba gateways and controllers official product page |
| Performance and Capacity | ||
| Maximum campus or remote AP licenses | 1,024 | |
| Maximum concurrent users/devices | 24,576 | |
| Maximum VLANs | 4,096 | |
| Active firewall sessions | 2M | |
| Concurrent GRE tunnels | 16,384 | |
| Concurrent IPsec sessions | 24,576 | |
| Concurrent SSL sessions | 8,192 | |
| Firewall throughput (Gbps) | 40 | |
| Wired Bridged Throughput (Gbps) | 40 | |
| Encrypted throughput 3DES (Gbps) | 25 | |
| Encrypted throughput AES-CBC-256 (Gbps) | 22 | |
| Encrypted throughput AES-CCM (Gbps) | 20 | |
| Encrypted throughput AES-GCM-256 (Gbps) | 26 | |
| Interfaces and Indicators | ||
| Form factor/footprint | 1xRU | |
| 10/100/1000BASE-T | 2xCombo | |
| 1000BASE-X | 2xCombo | |
| 10G Ports (10G or 1G supported) | 4xSFP+ | |
| 40G Ports | - | |
| USB 2.0 | 1 | |
| Management/status LEDs | Yes | |
| LINK/ACT and status LEDs | Yes | |
| LCD panel and navigation buttons | Yes | |
| Console port | mini USB, RJ45 | |
| Out-of-band management port | Yes | |
| Physical | ||
| Dimensions (HxWxD) | (H) 4.4 cm x (W) 44.5 cm x (D) 44.5 cm (1.75” x 17.5” x 17.5”) | |
| Weight | 7.45 kg (16.43 lbs.) | |
| MTBF (Hours) | 113,751 (@40C) | |
| Environmental | ||
| Operating Temperature | 0° C to 40° C | |
| Storage Temperature | -40° C to 70° C | |
| Humidity/Storage Humidity | 5% to 95%, NC | |
| Operating Altitude | 10,000 feet | |
| Acoustic Noise¹ | 52.9 dBA | |
| Maximum Heat Dissipation (BTU/hour) | 427 | |
| Maximum Power Consumption | 125W | |
| Power Source | 350-watt AC or DC power supply | |
| Power Adapter and Supply Specifications | ||
| Features | 350-watt AC | 350-watt DC |
| Input voltage range | 100 VAC to 240 VAC | DC -48V to DC -60V |
| Output Voltage | +12VDC, 29.16A | +12VDC, 29.16A |
| Input frequency | 50-60 Hz | 50-60 Hz |
| AC line input current (steady state) | 5 - 2.5A | 5 - 2.5A |
| Operating Temperature | -5° to +55° C | -5° to +55° C |
| Cooling | Internal fan (Air flow rear to front) | |
| Weight | 1.3 kg (2.8 lbs) | |
| Regulatory and Safety Compliance | ||
| Regulatory SKU information | ARCN0101 | |
| Minimum HPE ArubaOS Release | 6.2.0.0 802.11ax (Wi-Fi 6), AOS 8.4; WI-FI CERTIFIED WPA3™, AOS 8.4; WI-FI CERTIFIED Enhanced Open™, AOS 8.4 | |
| Regulatory and Safety Compliance | FCC Part 15 Class A, CE Industry Canada Class A VCCI Class A (Japan) EN 55022 Class A (CISPR 22 Class A), EN 61000-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 55024, AS/NZS 3548 UL 60950, EN60950 CAN/CSA 22.2 #60950 CE mark, cTUVus, CB, C-tick, Anatel, NOM, MIC | |
| Telco | Common Language Equipment Identifier (CLEI) Code | |
JW649A Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | 100% Money Back Guarantee |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
JW649A FAQ
What is JW649A?
JW649A Aruba 7220DC (RW) 4p 10GBase-X 2p Dual Pers 350W DC Pwr Cntrlr is a ARUBA HPE Aruba 7200 Series Mobility Controllers product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the datasheet series of JW649A?
The listed datasheet series for JW649A is HPE Aruba Mobility Controllers. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the exact model of JW649A?
The listed exact model for JW649A is JW649A. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is JW649A available from YYST Global?
YYST Global can help check availability, lead time and configuration for JW649A. Contact the sales team before ordering to confirm current stock.
What is the price of JW649A?
The current reference price for JW649A is US$ 200.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
