USG6315E-AC - Huawei Next-Generation Firewalls

Identify the AC appliance and its revision

USG6315E-AC is a Huawei USG6000E firewall. The official 02353AFP ordering description lists two GE WAN interfaces, eight GE Combo interfaces and two 10GE SFP+ interfaces, together with one AC supply and SSL VPN support for 100 users. These are the documented base-order inclusions, not a statement of the quoted unit’s installed subscriptions.

Match the software baseline to the part label

Huawei lists V600R007C00 as the starting supported version for 02353AFP. Its hardware center also lists 02353AFP-001 and 02353AFP-002 under the same model, so record the full part number when specifying a replacement. The specifications below refer to the original 02353AFP record; confirm later revisions independently rather than assuming the same software minimum.

Plan rack space and power resilience

The original part is a 1U rack or tabletop appliance. Huawei lists a cabinet depth of at least 600 mm, typical consumption of 35 W and maximum consumption of 40 W. One pluggable AC supply is listed; a second supply is an optional purchase for 1+1 redundancy. Two installed supplies must therefore be verified before promising redundant power.

Keep optional storage and security services explicit

The M.2 solid-state drive is optional in the hardware record. Ask for a component and entitlement inventory when the project needs local storage or security services beyond the stated base SSL VPN users. Check the power supply, transceivers, software release and actual hardware revision against the intended deployment before ordering.

Huawei official exact-part hardware record
