HUAWEI S1720-28GFR-4TP S1700 Series Switches
- 763 412 7282
- +86 010 69614620
S1720-28GFR-4TP Buying Guide
S1720-28GFR-4TP Huawei S1700 Series Switch is listed by YYST Global for buyers looking for HUAWEI Huawei S1700 Series Switches. S1720-28GFR-4TP HUAWEI enterprise network switch for network refresh projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 115.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: S1720-28GFR-4TP
- Brand: HUAWEI
- Category: Huawei S1700 Series Switches
- Condition: New Factory Sealed
- Reference price: US$ 115.00
S1720-28GFR-4TP Overview
S1720-28GFR-4TP is a HUAWEI enterprise network switch listed by YYST Global for campus switching, data center expansion, spare replacement and network refresh projects. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: S1720-28GFR-4TP Huawei S1700 Series Switch. Category: Huawei S1700 Series Switches. Condition: New Factory Sealed.
S1720-28GFR-4TP Specification
Table 1 shows the Quick Specs.
Product Code | S1720-28GFR-4TP |
Type | Web/SNMP-based Switch |
Downlink Ports | 24 Ethernet 10/100/1000 ports |
Uplink Ports | 2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP |
MAC Address | 16 K MAC |
Forwarding Performance | 42 Mpps |
Switching Capacity | 128 Gbit/s |
Input Voltage | 100 V to 240 V AC, 50/60 Hz |
Heat Dissipation | Fan-free natural heat dissipation |
Dimensions (W x D x H) | 44.2cm × 22cm × 4.36cm |
Weight (Kg) | 3.56 Kg |
Product Details
Figure 2 shows the front panel of Huawei S1720-28GFR-4TP switch.
Note：
① | 24 × 10/100/1000BASE-T ports | ④ | One console port |
② | 2 × 1000BASE-X Ethernet ports | ⑤ | Reset button |
③ | 2 × combo ports (10/100/1000BASE-T + 100/1000BASE-X) | ⑥ | Mode switching button |
Figure 3 shows the front indicators of Huawei S1720-28GFR-4TP switch.
Table 2 shows the numbers’ descriptions.
No. | Indicator/Button | Color | Description |
① | Service port indicator | Meanings of service port indicators vary in different modes. See the Table 3. | |
② | PWR : power indicator | Off | The switch is powered off. |
Green | Steady on: The power module is supplying power normally. | ||
③ | SYS: system status indicator | Off | The system is not running. |
Green | - Fast blinking: The system is starting. - Slow blinking: The system is running normally. | ||
Red | Steady on: The system does not work normally after registration, or a temperature alarm has been generated. | ||
④ | SPED: speed indicator | Off | The speed mode is not selected. |
Green | Steady on: The speed mode is selected. In this mode, service port indicators show port speeds. After 45 seconds, the service port indicators automatically restore to the status mode. | ||
⑤ | MODE: mode switch button | - Press this button once, the service port indicators change to the speed mode and show the speed of each service port. - Press this button again, the service port indicators restore to the default mode and show the connection status of each service port. - If you do not press this button within 45 seconds, the service port indicators restore to the default mode. In this case, the SPED indicator is off. | |
Table 3 shows the Service port indicators’ descriptions.
Service port indicators | Color | Description |
Default mode | Off | No connection is set up on the port or the port has been shut down. |
Green | Steady on: The port is connected. | |
Blinking: The port is transmitting or receiving data. | ||
Speed mode | Green | Off: The port is not connected or has been shut down. |
Steady on: The port is operating at 10/100 Mbit/s. | ||
Blinking: The port is operating at 1000 Mbit/s. |
Figure 4 shows the back panel of Huawei S1720-28GFR-4TP switch.
Note：
① | Ground screw |
② | Jack reserved for AC terminal locking latch |
③ | AC power socket |
The Optical Transceiver
Table 4 shows the recommended optical transceivers for 1720-28GFR-4TP.
Models | Description |
Optical Transceiver,SFP,100M/155M,Multi-mode Module(1310nm,2km,LC) | |
Optical Transceiver,eSFP,100M/155M,Single-mode Module(1310nm,15km,LC) | |
Optical Transceiver, eSFP, FE, Single-mode Module(1310nm,40km,LC) | |
Electrical Transceiver, SFP, GE, Electrical Interface Module(100m,RJ45) | |
Optical Transceiver, eSFP, GE, Multi-mode Module(850nm,0.55km,LC) | |
Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,10km,LC) | |
Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,40km,LC) | |
Optical Transceiver, eSFP, GE, Single-mode Module(1550nm,40km,LC) |
Compare to Similar Item
Table 5 shows the comparison between S1720-20GFR-4TP and S1720-28GFR-4TP.
Model | S1720-28GFR-4TP | |
Downlink Ports | 16 Ethernet 10/100/1,000 ports | 24 Ethernet 10/100/1,000 ports |
Uplink Ports | 2 Gig SFP and 2 dual-purpose 10/100/1,000 or SFP | 2 Gig SFP and 2 dual-purpose 10/100/1,000 or SFP |
Forwarding Performance | 30 Mpps | 42 Mpps |
Switching Capacity | 128 Gbit/s | 128 Gbit/s |
| Exact product model | S1720-28GFR-4TP |
| Product family | Huawei campus switch |
| Official Huawei documentation | Huawei Enterprise Support results for S1720-28GFR-4TP |
| Specification validation | Match the exact order code, suffix, region, power option, software version and required licenses against Huawei documentation before purchase. |
S1720-28GFR-4TP Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | 100% Money Back Guarantee |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
S1720-28GFR-4TP FAQ
What is S1720-28GFR-4TP?
S1720-28GFR-4TP Huawei S1700 Series Switch is a HUAWEI Huawei S1700 Series Switches product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the product code of S1720-28GFR-4TP?
The listed product code for S1720-28GFR-4TP is S1720-28GFR-4TP. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the type of S1720-28GFR-4TP?
The listed type for S1720-28GFR-4TP is Web/SNMP-based Switch. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is S1720-28GFR-4TP available from YYST Global?
YYST Global can help check availability, lead time and configuration for S1720-28GFR-4TP. Contact the sales team before ordering to confirm current stock.
What is the price of S1720-28GFR-4TP?
The current reference price for S1720-28GFR-4TP is US$ 115.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
