AD9430DN-24-FAT Buying Guide
AD9430DN-24-FAT Huawei AD9000 Fat-mode 24 GE PoE Ports Central AP is listed by YYST Global for buyers looking for HUAWEI Huawei AD9000 Series Access Points. AD9430DN-24-FAT HUAWEI wireless networking hardware for campus WLAN projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 700.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: AD9430DN-24-FAT
- Brand: HUAWEI
- Category: Huawei AD9000 Series Access Points
- Condition: New Factory Sealed
- Reference price: US$ 700.00
AD9430DN-24-FAT Overview
AD9430DN-24-FAT is a HUAWEI wireless networking hardware listed by YYST Global for campus WLAN expansion, controller replacement, access point rollout and wireless refresh projects. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: AD9430DN-24-FAT Huawei AD9000 Fat-mode 24 GE PoE Ports Central AP. Category: Huawei AD9000 Series Access Points. Condition: New Factory Sealed.
AD9430DN-24-FAT Specification
| PoE port surge protection | PoE interface: Differential mode (48 V-RTN), ±0.5 kV ; Common mode: ±4kV; Non-PoE interface: Common mode: ±4kV; |
| Ingress protection | IP20 |
| Atmospheric pressure | 53~106Kpa ETSI 300 019-2-3 |
| Ground/floating ground | Ground |
| Altitude | The device works properly if the altitude is between -60 m and 5000 m; If the altitude is higher than 1800 m, the temperature decreases by 1℃ every time the altitude increases by 300 m. |
| Operating temperature | Operating temperature: 0~45℃ Storage temperature: -40~70℃ |
| Humidity | 5%~95% |
| Certification of Radio Association of China | No need for CMIIT ID; network license of industry & information department |
| Safety certification | EN 60950-1 |
| Environment certification | RoHS |
| Power consumption of the device | 435 W (device itself: 55 W; PoE out: 380 W) |
| Ethernet ports | 24*10/100/1000BASE-T(PoE out)＋4*GE COMBO |
| Console port | RJ45 ×1 |
| Weight (kg) | 4.4kg(without package) 5.5kg(with package) |
| Dimensions (W x D x H) (mm) | 442*312*43.6 |
| LED indicator | Supported |
| Optical module type | eSFP; support BiDi module- |
| AC power supply | built-inrated voltage: 100 V to 240 V AC; 50/60 Hz Maximum voltage: 90 V to 264 V AC; 47 Hz to 63 Hz Maximum output power: 440 W (include 370W PSE out) |
| PoE out power supply (input) | Built-in. rated voltage: 100 V to 240 V AC; 50/60 Hz Maximum voltage: 90 V to 264 V AC; 47 Hz to 63 Hz |
| Exact product model | AD9430DN-24-FAT |
| Product family | Huawei WLAN controller or distributed access unit |
| Official Huawei documentation | Huawei Enterprise Support results for AD9430DN-24-FAT |
| Specification validation | Match the exact order code, suffix, region, power option, software version and required licenses against Huawei documentation before purchase. |
AD9430DN-24-FAT Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | 100% Money Back Guarantee |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
AD9430DN-24-FAT FAQ
What is AD9430DN-24-FAT?
AD9430DN-24-FAT Huawei AD9000 Fat-mode 24 GE PoE Ports Central AP is a HUAWEI Huawei AD9000 Series Access Points product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the poe port surge protection of AD9430DN-24-FAT?
The listed poe port surge protection for AD9430DN-24-FAT is PoE interface: Differential mode (48 V-RTN), ±0.5 kV ; Common mode: ±4kV; Non-PoE interface: Common mode: ±4kV;. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the ingress protection of AD9430DN-24-FAT?
The listed ingress protection for AD9430DN-24-FAT is IP20. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is AD9430DN-24-FAT available from YYST Global?
YYST Global can help check availability, lead time and configuration for AD9430DN-24-FAT. Contact the sales team before ordering to confirm current stock.
What is the price of AD9430DN-24-FAT?
The current reference price for AD9430DN-24-FAT is US$ 700.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
