Fortinet FN-TRAN-SFP+BD33 10 GE SFP+ BiDi 30 km Transceiver
- 763 412 7282
- +86 010 69614620
FN-TRAN-SFP+BD33 Overview
30 km 10 GE bidirectional SFP+ optic
FN-TRAN-SFP+BD33 is Fortinet's 10 GE SFP+ BiDi module for a 30 km single-mode-fiber link. It transmits at 1331 nm and receives at 1271 nm through one LC connector.
Required opposite-end optic
This is one side of a bidirectional optical pair. Fortinet specifies FN-TRAN-SFP+BD27 as the complementary module and states that it is ordered separately. A same-wavelength optic at both ends is not a valid substitution.
Electrical and environmental boundary
The official specification lists 10G-Base-LR/LW, IEEE 802.3ae, an 11.3 Gbps data-link rate, power below 1 W, and an operating range from -5°C to 85°C. The module supports hot plug, serial ID PROM, digital monitoring, auto negotiation and link status.
Procurement and commissioning checks
Confirm SFP+ host support at both Fortinet endpoints, the 30 km loss budget, single-mode fiber and LC cleanliness. Record the BD33/BD27 direction, endpoint serials, receive levels and link test; this module is not a duplex-LC optic or a four-pack.
Official evidence: Fortinet Transceivers Data Sheet, specification page 5 and ordering page 13.
FN-TRAN-SFP+BD33 Specification
| Exact model / SKU | FN-TRAN-SFP+BD33 |
| Exact Fortinet SKU | FN-TRAN-SFP+BD33 |
| Product type | 10 GE bidirectional SFP+ transceiver |
| Protocol / IEEE | 10G-Base-LR/LW / 802.3ae |
| Data-link rate | 11.3 Gbps |
| Transmission range | 30 km |
| Media | Single-mode fiber (SM) |
| Wavelengths | TX: 1331 nm; RX: 1271 nm |
| Connector | Single LC |
| Power dissipation | Less than 1 W |
| Operating temperature | -5°C to 85°C |
| Monitoring | Serial ID PROM and digital monitoring |
| Required pair | FN-TRAN-SFP+BD27, ordered separately |
| Hardware included | One transceiver module; opposite-end optic is separate |
| Source match | FN-TRAN-SFP+BD33: exact Fortinet specification and ordering rows visually verified on official PDF pages 5 and 13 |
| Official manufacturer reference | Fortinet Transceivers Data Sheet - FN-TRAN-SFP+BD33 |
FN-TRAN-SFP+BD33 Ordering Information
This listing is an accessory or component and may not include the main device. Confirm the supported platform, connector or form factor, included quantity, hardware revision and required mounting or installation parts before ordering.
Document/Firmware Download
FN-TRAN-SFP+BD33 FAQ
What is FN-TRAN-SFP+BD33 used for?
Fortinet FN-TRAN-SFP+BD33 10 GE SFP+ BiDi 30 km Transceiver is a FORTINET accessory or component in the Transceiver Modules category. It may require a compatible main device and should not be treated as a complete standalone system.
Which products are compatible with FN-TRAN-SFP+BD33?
Compatibility depends on the exact parent platform, chassis or device revision. Provide the installed model and required quantity so YYST Global can check fit before ordering.
What is included with FN-TRAN-SFP+BD33?
Confirm whether the quotation includes only the named component or also includes cables, brackets, optics, licenses or installation hardware. Package contents vary by part number and condition.
What is the price of FN-TRAN-SFP+BD33?
The current reference price for FN-TRAN-SFP+BD33 is US$ 211.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
