FAP-423E Buying Guide
FAP-423E - FortiAP 423E Indoor Access Points Dual Radio is listed by YYST Global for buyers looking for FORTINET FortiAP Standard Access Points. FAP-423E FORTINET wireless networking hardware for campus WLAN projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 621.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: FAP-423E
- Brand: FORTINET
- Category: FortiAP Standard Access Points
- Condition: New Factory Sealed
- Reference price: US$ 621.00
FAP-423E Overview
FAP-423E is a FORTINET wireless networking hardware listed by YYST Global for campus WLAN expansion, controller replacement, access point rollout and wireless refresh projects. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: FAP-423E - FortiAP 423E Indoor Access Points Dual Radio. Category: FortiAP Standard Access Points. Condition: New Factory Sealed.
FAP-423E Specification
| Datasheet series | Fortinet FortiAP Access Points |
| Exact model | FAP-423E |
| Product role | Enterprise FortiAP wireless access point; confirm radio generation, country domain and mounting kit |
| Management check | Confirm FortiGate/FortiWLC/FortiCloud management mode and firmware compatibility |
| Procurement check | Confirm power option, accessories, warranty/support term, region and project compatibility |
| Procurement validation | Confirm exact part number, condition, licenses, accessories, power/airflow option, warranty, stock and lead time before purchase |
| Official datasheet | Fortinet FortiAP official product documentation |
| Hardware | |
| Hardware Type | Indoor |
| Number of Radios | 2 |
| Number of Antennas | 8 RP-SMA External |
| Peak Antenna Gain | 3 dBi for 2.4 GHz, |
| 3 dBi for 5 GHz | |
| Frequency Bands (GHz) * | 2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.851 |
| Frequency of Radio 1 | 2.4 GHz b/g/n (4x4:4 stream) QCA9980 20/40 Mhz (256 QAM) |
| Frequency of Radio 2 | 5 GHz a/n/ac (4x4:4 stream) QCA9980 20/40/80 Mhz (256 QAM) |
| Maximum Data Rate | Radio 1: up to 600 Mbps |
| Radio 2: up to 1.733 Gbps | |
| Ethernet Ports | 2x GE RJ45 |
| USB Port | 1x Type A |
| Serial Console Port | 1 RS-232 x RJ45 |
| Power over Ethernet (PoE) | Dual redundant PoE power ports with support for IEEE 802.3at (25.5 W) |
| Simultaneous SSIDs | 16 (14 if background scanning enabled) |
| EAP Type(s) | EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC EAP-SIM, EAP-AKA, EAP-FAST |
| User/Device Authentication | WPA and WPA2 with 802.1X or Preshared key, WEP and Web Captive Portal, MAC blacklist & whitelist |
| Maximum Tx Power | 19 dBm (80 mW)* |
| Physical Security | Kensington Lock |
| IEEE Specifications | 802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11n, 802.1x, 802.11ac, 802.3at, 802.3az, 802.3ad (LACP support) |
| FortiPresence Capable | Yes |
| Wireless Mesh Capable | Yes |
| Concurrent Clients Per Radio (Maximum / Recommended) | 512 / 128 |
| Advanced 802.11 Features | |
| 802.11ac Wave2 MU-MIMO | Yes |
| Transmit Beam Forming (TxBF) | Yes |
| Low-Density Parity Check (LDPC) Encoding | Yes |
| Maximum Likelihood Demodulation (MLD) | Yes |
| Maximum Ratio Combining (MRC) | Yes |
| A-MPDU and A-MSDU Packet Aggregation | Yes |
| MIMO Power Save | Yes |
| Short Guard Interva | Yes |
| WME Multimedia Extensions | Yes (4 priority queues for voice, video, data and background traffic) |
| Wireless Monitoring Capabilities | |
| Frequencies scanned | 2.4 and 5 GHz |
| Background scan with client access on2.4 and 5 GHz | Yes |
| Full-time scan as dedicated monitor | Yes |
| Full-time scan with client access on 5G GHz | No |
| Dimensions | |
| Length x Width x Height | 8.5 x 8.5 x 2.2 inches (215 x 215 x 56 mm) |
| Weight | 3.57 lb (1.62 kg) |
| Package (shipping) Weight | 5.3 lb (2.4 kg) |
| Mounting Options | Ceiling, T-Rail and wall |
| Included Accessories | Ceiling, T-Rail and wall mount kit and 8 dipole antennas (AC power adapter sold seperately) |
| Environment | |
| Power Supply | Adapter Input: 100–240V, 50/60Hz, 0.9A Maximum Output: 12V DC, 3A |
| Power Consumption (Average / Maximum) | 20 W / 23 W |
| Humidity | 5–90% non condensing |
| Operating Temperature | -4–122x°F (-20–50°C) |
| Storage Temperature | -40–158°F (-40–70°C) |
| Directives | Low Voltage Directive • RoHS |
| UL2043 Plenum Material | Yes |
| Mean Time Between Failures | >30 Years |
| Certifications | |
| WiFi Alliance Certified | In Process |
| DFS Certified | In Process |
| Warranty | |
| Limited Lifetime Warranty | Yes |
FAP-423E Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | 100% Money Back Guarantee |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
FAP-423E FAQ
What is FAP-423E?
FAP-423E - FortiAP 423E Indoor Access Points Dual Radio is a FORTINET FortiAP Standard Access Points product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the datasheet series of FAP-423E?
The listed datasheet series for FAP-423E is Fortinet FortiAP Access Points. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the exact model of FAP-423E?
The listed exact model for FAP-423E is FAP-423E. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is FAP-423E available from YYST Global?
YYST Global can help check availability, lead time and configuration for FAP-423E. Contact the sales team before ordering to confirm current stock.
What is the price of FAP-423E?
The current reference price for FAP-423E is US$ 621.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
