FORTINET FAP-221E-T FortiAP FAP-221E
- 763 412 7282
- +86 010 69614620
FAP-221E-T Buying Guide
FAP-221E-T-FortiAP-221E 802.11ac Wave 2 dual radio 4 internal Antennas is listed by YYST Global for buyers looking for FORTINET FortiAP FAP-221E. FAP-221E-T FORTINET enterprise IT hardware. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 200.00. Contact our sales team to validate compatibility, scope, fulfillment and lead time before ordering.
- Model: FAP-221E-T
- Brand: FORTINET
- Category: FortiAP FAP-221E
- Condition: New Factory Sealed
- Reference price: US$ 200.00
FAP-221E-T Overview
FAP-221E-T is a FORTINET enterprise IT hardware listed by YYST Global for enterprise hardware procurement, replacement projects and infrastructure expansion. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: FAP-221E-T-FortiAP-221E 802.11ac Wave 2 dual radio 4 internal Antennas. Category: FortiAP FAP-221E. Condition: New Factory Sealed.
FAP-221E-T Specification
| Hardware | ||
| Indoor/Outdoor Deployment | Indoor AP | |
| Number of Radios | 2 | |
| Number of Antennas | 4 Internal | |
| Peak Antenna Gain | Patch: 4 dBi for 2.4 GHz, 5 dBi for 5 GHz | |
| Frequency Bands (GHz)* | 2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850 | |
| Radio 1 Capabilities | 2.4 GHz b/g/n (2x2:2 stream) 20/40 MHz (256 QAM) | |
| Radio 2 Capabilities | 5 GHz a/n/ac (2x2:2 stream) 20/40/80 MHz (256 QAM) | |
| Maximum Data Rate | Radio 1: up to 400 Mbps Radio 2: up to 867 Mbps | |
| Bluetooth Low Energy (BT/BLE) Radio | — | |
| Interfaces | 1x 10/100/1000 Base-T RJ45, 1x Type A USB | |
| Power over Ethernet (PoE) | IEEE 802.3af | |
| Simultaneous SSIDs | 16 (14 if background scanning enabled) | |
| EAP Type(s) | EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-FAST | |
| User/Device Authentication | WPA and WPA2 with 802.1x or Preshared key, WEP, Web Captive Portal, MAC blacklist & whitelist | |
| Maximum Tx Power | 2.4 GHz: 23 dBm / 200 mW (2 chains combined)** 5 GHz: 24 dBm / 251 mW (2 chains combined)** | |
| Kensington Lock | Yes | |
| IEEE Standards | 802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.11ac, 802.1X, 802.3af, 802.3az | |
| SSID Types Supported | Local-Bridge, Tunnel, Mesh | |
| Per Radio Client Capacity | Up to 512 | |
| Cellular Co-existence | Yes | |
| LED Off Mode | Yes | |
| Advanced 802.11 Features | ||
| 802.11ac Wave 2 MU-MIMO | Yes | |
| Transmit Beam Forming (TxBF) | Yes | |
| Low-Density Parity Check (LDPC) Encoding | Yes | |
| Maximum Likelihood Demodulation (MLD) | Yes | |
| Maximum Ratio Combining (MRC) | Yes | |
| 802.11ac 20/40/80 MHz Channel | Yes | |
| A-MPDU and A-MSDU Packet Aggregation | Yes | |
| MIMO Power Save | Yes | |
| Short Guard Interval | Yes | |
| Wireless Monitoring Capabilities | ||
| Rogue Scan Radio Modes | Background, Full-time | |
| WIPS / WIDS Radio Modes | Background, Full-time | |
| Packet Sniffer Mode | Yes | |
| Spectrum Analyzer | Yes | |
| Dimensions | ||
| Length x Width x Height | 6.3 x 6.3 x 1.85 inches (160 x 160 x 47 mm) | |
| Weight | 1.1 lbs (0.5 kg) | |
| Package (shipping) Weight | 4.95 lbs (2.2 kg) | |
| Mounting Options | Ceiling, T-Rail and Wall | |
| Included Accessories | Mount kits for Ceiling, T-Rail, and Wall | |
| Environment | ||
| Power Supply | Adapter Input: 100–240V, 50/60Hz, 0.4A Output: 12V DC, 2A | |
| Power Consumption (Max.) | 7.8 W | |
| Humidity | 5% to 90% non-condensing | |
| Operating Temperature | -4 to 122˚F (-20 to 50˚C) | |
| Storage Temperature | -40 to 158˚F (-40 to 70˚C) | |
| Directives | Low Voltage Directive • RoHS2 | |
| UL2043 Plenum Material | Yes | |
| Mean Time Between Failures | >30 Years | |
| IP Rating | — | |
| Surge Protection Built In | — | |
| Hit-less PoE Failover | No | |
| Certifications | ||
| WiFi Alliance Certified | Yes | |
| DFS | FCC, IC, CE, Japan, Taiwan | |
| Certifications | ||
| Limited Lifetime Warranty | Yes | |
FAP-221E-T Ordering Information
This listing is an accessory or component and may not include the main device. Confirm the supported platform, connector or form factor, included quantity, hardware revision and required mounting or installation parts before ordering.
FAP-221E-T FAQ
What is FAP-221E-T used for?
FAP-221E-T-FortiAP-221E 802.11ac Wave 2 dual radio 4 internal Antennas is a FORTINET accessory or component in the FortiAP FAP-221E category. It may require a compatible main device and should not be treated as a complete standalone system.
Which products are compatible with FAP-221E-T?
Compatibility depends on the exact parent platform, chassis or device revision. Provide the installed model and required quantity so YYST Global can check fit before ordering.
What is included with FAP-221E-T?
Confirm whether the quotation includes only the named component or also includes cables, brackets, optics, licenses or installation hardware. Package contents vary by part number and condition.
What is the price of FAP-221E-T?
The current reference price for FAP-221E-T is US$ 200.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
