CISCO C1-ASR1002-HX/K9 Router ASR 1000
- 763 412 7282
- +86 010 69614620
C1-ASR1002-HX/K9 Buying Guide
C1-ASR1002-HX/K9 - Cisco One ASR 1000 Aggregation Services Routers is listed by YYST Global for buyers looking for CISCO Cisco Router ASR 1000. C1-ASR1002-HX/K9 CISCO enterprise router for WAN edge projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 29,360.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: C1-ASR1002-HX/K9
- Brand: CISCO
- Category: Cisco Router ASR 1000
- Condition: New Factory Sealed
- Reference price: US$ 29,360.00
C1-ASR1002-HX/K9 Overview
C1-ASR1002-HX/K9 is a CISCO enterprise router listed by YYST Global for WAN edge routing, branch connectivity, spare replacement and enterprise routing upgrades. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: C1-ASR1002-HX/K9 - Cisco One ASR 1000 Aggregation Services Routers. Category: Cisco Router ASR 1000. Condition: New Factory Sealed.
C1-ASR1002-HX/K9 Specification
| Datasheet series | Cisco ASR 1000 Series Aggregation Services Routers |
| Exact model | C1-ASR1002-HX/K9 |
| Product role | Edge aggregation router; confirm chassis, route processor, ESP, SIP/SPA modules, licenses and power |
| Primary validation | route processor, ESP throughput and interface modules |
| Procurement check | license level, redundancy and power option |
| Procurement validation | Confirm exact part number, condition, licenses, accessories, power/airflow option, warranty, stock and lead time before purchase |
| Official datasheet | Cisco ASR 1000 Series official product page |
C1-ASR1002-HX/K9 Specification | |
Physical specifications | Height: 3.5 in. (88.9 mm) Width: 17.3 in. (439.4 mm) Depth: 19.25 in. (489.0 mm) Weight: ● 34 lb (15.45 kg) (with dual AC power supplies) ● 34 lb (15.45 kg) (with dual DC power supplies) |
Default memory | 16-GB DRAM shared across route processor, ESP, and MIP |
Number of SIPs or Ethernet line cards supported | Integrated in chassis |
Shared port adapters | N/A |
Ethernet port adapters | 1 EPA slot |
Cisco ASR 1000 Series ESP | Integrated in chassis |
Route processor | Integrated in the chassis: Cisco ASR 1002-HX Series Route Processor |
Redundancy | Software: Yes |
Built-in Gigabit Ethernet ports | Yes: 8 Gigabit Ethernet SFP ports |
Built-in 10 Gigabit Ethernet port | Yes: Eight 10 Gigabit Ethernet Small Form-Factor Plus Pluggable (SFP+) ports Note:Built-in 10-GB ports cannot be reduced to 1-GB speed. |
Network interface module | Yes |
ESP support | Cisco ASR 1000 Series 100-Gbps ESP (ASR1000-ESP100) equivalent |
ESP bandwidth | 100 Gbps |
ESP memory | Share the same control memory on route processor |
SIPs and Ethernet line cards | Integrated in chassis: not upgradable |
Embedded hardware-based encryption | Yes: Up to 25-Gbps crypto support throughput |
Minimum Cisco IOS XE Software release | Cisco IOS XE Software Release 16.2.1S |
Rack-mounting | Yes: 19-inch |
Wall-mounting | No |
External USB flash memory | 1-GB USB flash-memory support |
Redundant power supply | Yes: Dual power supplies by default; option of either AC or DC power supply Note: A mix of one AC and one DC power supply is not supported. |
Power input | Worldwide ranging AC input range (85 to 264 VAC) Worldwide ranging DC (-40 to -72; -48V nominal) |
Power consumption | ● Maximum (DC): 500W ● Maximum (AC): 500W |
Airflow | Front-to-back |
Operating temperature (nominal) | 32 to 104°F |
Operating temperature (short-term) | 32 to 122°F |
Operating humidity (nominal) (relative humidity) | 10 to 85% |
Operating humidity (short-term) | 5 to 90% |
Storage temperature | -40 to 150°F (-40 to 70°C) |
Storage humidity (relative humidity) | 5 to 95% |
Operating altitude | -500 to 10,000 feet |
Network Equipment Building Standards (NEBS) | GR-1089 and GR-63 |
EMC standards | Emissions ● FCC 47CFR15 Class A ● AS/NZS CISPR 22 ● CISPR 22 Class A ● EN55022 Class A ● ICES-003 Class A ● VCCI Class A ● CNS-13438 Class A ● EN61000-3-2 ● EN61000-3-3 Immunity ● IEC/EN61000-4-2 Electrostatic Discharge Immunity ● IEC/EN61000-4-3 Radiated Immunity ● IEC/EN61000-4-4 EFT-B Immunity ● IEC/EN61000-4-5 Surge ● IEC/EN61000-4-6 Immunity to Conducted Disturbances ● IEC/EN61000-4-8 Power Frequency Magnetic Field Immunity ● IEC/EN61000-4-11 Voltage Dips, Short Interruptions, and Voltage Variations ETSI/EN ● EN55022/CISPR 22 Information Technology Equipment (Emissions) ● EN55024/CISPR 24 Information Technology Equipment (Immunity) ● EN300 386 Telecommunications Network Equipment ● EN50082-1/EN61000-6-1 Generic Immunity Standard |
Safety Standard | UL60950-1 CSA C22.2 No. 60950-1-03 EN 60950-1 IEC 60950-1 AS/NZS 60950.1 |
C1-ASR1002-HX/K9 Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | Free CCIE Expert Technical Support |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
C1-ASR1002-HX/K9 FAQ
What is C1-ASR1002-HX/K9?
C1-ASR1002-HX/K9 - Cisco One ASR 1000 Aggregation Services Routers is a CISCO Cisco Router ASR 1000 product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the datasheet series of C1-ASR1002-HX/K9?
The listed datasheet series for C1-ASR1002-HX/K9 is Cisco ASR 1000 Series Aggregation Services Routers. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the exact model of C1-ASR1002-HX/K9?
The listed exact model for C1-ASR1002-HX/K9 is C1-ASR1002-HX/K9. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is C1-ASR1002-HX/K9 available from YYST Global?
YYST Global can help check availability, lead time and configuration for C1-ASR1002-HX/K9. Contact the sales team before ordering to confirm current stock.
What is the price of C1-ASR1002-HX/K9?
The current reference price for C1-ASR1002-HX/K9 is US$ 29,360.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
