S5700-28C-HI-24S-AC Buying Guide
Huawei S5700-28C-HI-24S-AC S5700 Series Switch is listed by YYST Global for buyers looking for HUAWEI Huawei Switches. S5700-28C-HI-24S-AC HUAWEI enterprise network switch for network refresh projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 2,200.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: S5700-28C-HI-24S-AC
- Brand: HUAWEI
- Category: Huawei Switches
- Condition: New Factory Sealed
- Reference price: US$ 2,200.00
S5700-28C-HI-24S-AC Overview
S5700-28C-HI-24S-AC is a HUAWEI enterprise network switch listed by YYST Global for campus switching, data center expansion, spare replacement and network refresh projects. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: Huawei S5700-28C-HI-24S-AC S5700 Series Switch. Category: Huawei Switches. Condition: New Factory Sealed.
S5700-28C-HI-24S-AC Specification
| Item | Specification |
|---|---|
| Model Name | Huawei S5700-28C-HI-24S-AC |
| Series | S5700-HI |
| Switch Type / Layer | Layer-2 / Layer-3 capable, Aggregation / Access |
| Fixed Ports | 24 × 100/1000Base-X (SFP) ports |
| Extended Slot(s) | 1 extended slot for subcards |
| Supported Subcards (Examples) | 4 × 1000Base-X SFP subcard; 2 × 10GE SFP+ subcard; 4 × 10GE SFP+ subcard |
| Forwarding Performance | 96 Mpps (million packets per second) |
| Switching Capacity (Backplane Bandwidth) | 256 Gbps |
| MAC Address Table Size | ~ 32,000 MAC addresses |
| Memory (RAM) | 512 MB |
| Flash Memory | 64 MB |
| Power Supply | AC / DC double hot-swappable power modules |
| Rated Voltage Range | AC: 100-240 V AC, 50/60 Hz; DC: -48 V to -60 V DC |
| Maximum Voltage Range | AC: 90-264 V AC, 47-63 Hz; DC: -36 V to -72 V DC |
| Maximum Power Consumption (100% Throughput, Full Fan Speed) | Approximately 80.7 W |
| Operating Temperature | -5 °C to +55 °C (note: when using long-distance SFP+ optical modules ≥ 40 km, max temp may reduce) |
| Storage Temperature | -40 °C to +70 °C |
| Noise Level (Sound Power, ~27 °C) | < 60 dB(A) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Operating Altitude | With AC power modules: up to 5000 m; with DC power modules: up to 2000 m |
| Mean Time Between Failures (MTBF) | ~ 25.5 years (with 4-port 10GE subcard) to ~36.1 years (with 4-port GE SFP subcard) depending on configuration |
| Mean Time To Repair (MTTR) | ~ 2 hours |
| Availability | > 0.99999 (“five-nines”) |
| PoE Support | Not supported |
| RPS (Redundant Power Supply) | Not supported |
| Service Port Surge Protection | Not applicable |
| Power Supply Surge Protection | AC modules: ±6 kV differential mode and ±6 kV common mode; DC modules: ±1 kV differential, ±2 kV common mode |
| Dimensions (H × W × D) | ~ 44.4 mm × 442.0 mm × 220.0 mm |
| Weight | Empty: ≤ 5.0 kg; Fully configured: ≤ 6.5 kg |
| Exact product model | S5700-28C-HI-24S-AC |
| Product family | Huawei campus switch |
| Official Huawei documentation | Huawei Enterprise Support results for S5700-28C-HI-24S |
| Specification validation | Match the exact order code, suffix, region, power option, software version and required licenses against Huawei documentation before purchase. |
S5700-28C-HI-24S-AC Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | 100% Money Back Guarantee |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
S5700-28C-HI-24S-AC FAQ
What is S5700-28C-HI-24S-AC?
Huawei S5700-28C-HI-24S-AC S5700 Series Switch is a HUAWEI Huawei Switches product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the item of S5700-28C-HI-24S-AC?
The listed item for S5700-28C-HI-24S-AC is Specification. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the model name of S5700-28C-HI-24S-AC?
The listed model name for S5700-28C-HI-24S-AC is Huawei S5700-28C-HI-24S-AC. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is S5700-28C-HI-24S-AC available from YYST Global?
YYST Global can help check availability, lead time and configuration for S5700-28C-HI-24S-AC. Contact the sales team before ordering to confirm current stock.
What is the price of S5700-28C-HI-24S-AC?
The current reference price for S5700-28C-HI-24S-AC is US$ 2,200.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
