FORTINET FWF-61E FortiGate/FortiWiFi 60E Series
- 763 412 7282
- +86 010 69614620
FWF-61E Buying Guide
FWF-61E FortiWiFi 61E WiFi & Storage Security SD-WAN Firewall is listed by YYST Global for buyers looking for FORTINET FortiGate/FortiWiFi 60E Series. FWF-61E FORTINET security firewall appliance for security refresh projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed . The reference price is US$ 550.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: FWF-61E
- Brand: FORTINET
- Category: FortiGate/FortiWiFi 60E Series
- Condition: New Factory Sealed
- Reference price: US$ 550.00
FWF-61E Overview
FWF-61E is a FORTINET security firewall appliance listed by YYST Global for perimeter security refreshes, HA replacement, branch protection and security appliance sourcing. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: FWF-61E FortiWiFi 61E WiFi & Storage Security SD-WAN Firewall. Category: FortiGate/FortiWiFi 60E Series. Condition: New Factory Sealed.
FWF-61E Specification
| Datasheet series | Fortinet FortiGate 61E Series |
| Exact model | FWF-61E |
| Security appliance type | FortiWiFi / FortiGate integrated security appliance |
| Sizing check | Validate firewall, IPS, NGFW, threat protection and VPN throughput against the official datasheet before order |
| Interface check | Confirm RJ45/SFP/SFP+ port count, bypass port requirement and WAN redundancy before purchase |
| Subscription check | Confirm FortiGuard, support term, firmware requirement and HA pair compatibility |
| Procurement validation | Confirm exact part number, condition, licenses, accessories, power/airflow option, warranty, stock and lead time before purchase |
| Official datasheet | Fortinet FortiGate official hardware documentation |
| GE RJ45 WAN / DMZ Interfaces | 2 / 1 ports |
| GE RJ45 Internal Interfaces | 7 ports |
| USB Port | 1 port |
| Console (RJ45) Port | 1 port |
| Wireless Interface | 802.11 a/b/g/n/ac |
| Internal Storage | 1 x 128 GB SSD |
| IPS Throughput | 400 Mbps |
| NGFW Throughput | 250 Mbps |
| Threat Protection Throughput | 200 Mbps |
| Firewall Throughput (1518 / 512 / 64 byte UDP) | 3 / 3 / 3 Gbps |
| Firewall Latency (64 byte UDP packets) | 3 μs |
| Firewall Throughput (Packets Per Second) | 4.5 Mpps |
| Concurrent Sessions (TCP) | 1,300,000 |
| New Sessions/Second (TCP) | 30,000 |
| Firewall Policies | 5,000 |
| IPsec VPN Throughput (512 byte) | 2 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 500 |
| SSL-VPN Throughput | 150 Mbps |
| Concurrent SSL-VPN Users (Tunnel Mode, Max Recommended) | 200 |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 135 Mbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 135 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 75,000 |
| Application Control Throughput (HTTP 64K) | 650 Mbps |
| CAPWAP Throughput (HTTP 64K) | 890 Mbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiSwitches Supported | 16 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 30 / 10 |
| Maximum Number of FortiTokens | 500 |
| Maximum Registered FortiClient | 200 |
| High Availability Configurations | Active/Active, Active/Passive, Clustering |
| Height x Width x Length (inches) | 1.5 x 8.5 x 6.3 |
| Height x Width x Length (mm) | 38 x 216 x 160 |
| Weight | 1.9 lbs (0.9 kg) |
| Form Factor | Desktop |
| Power Requirement | 100–240V AC, 50–60 Hz, External 12 VDC adapter |
| Maximum Current | 115V AC / 0.9 A, 230V AC / 0.6 A |
| Power Consumption (Average / Maximum) | 13 / 16 W |
| Heat Dissipation | 55 BTU/h |
| Operating Temperature | 32–104°F (0–40°C) |
| Storage Temperature | -31–158°F (-35–70°C) |
| Humidity | 10–90% non-condensing |
| Noise Level | Fan-less 0 dBA |
| Operating Altitude | Up to 7,400 ft (2,250 m) |
| Regulatory Compliance | FCC Part 15 Class B, C-Tick, VCCI, CE, UL/cUL, CB |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN |
FWF-61E Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | 100% Money Back Guarantee |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
FWF-61E FAQ
What is FWF-61E?
FWF-61E FortiWiFi 61E WiFi & Storage Security SD-WAN Firewall is a FORTINET FortiGate/FortiWiFi 60E Series product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the datasheet series of FWF-61E?
The listed datasheet series for FWF-61E is Fortinet FortiGate 61E Series. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the exact model of FWF-61E?
The listed exact model for FWF-61E is FWF-61E. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is FWF-61E available from YYST Global?
YYST Global can help check availability, lead time and configuration for FWF-61E. Contact the sales team before ordering to confirm current stock.
What is the price of FWF-61E?
The current reference price for FWF-61E is US$ 550.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
