FORTINET FS-108F-POE FortiSwitch 100 Series Entry Switches
- 763 412 7282
- +86 010 69614620
FS-108F-POE Buying Guide
FS-108F-POE-Fortinet Network 8xGE RJ45 + 2 SFP Access Switch is listed by YYST Global for buyers looking for FORTINET Fortinet FortiSwitch 100 Series Entry Switches. FS-108F-POE FORTINET enterprise network switch for network refresh projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 320.00. Contact our sales team to validate compatibility, scope, fulfillment and lead time before ordering.
- Model: FS-108F-POE
- Brand: FORTINET
- Category: Fortinet FortiSwitch 100 Series Entry Switches
- Condition: New Factory Sealed
- Reference price: US$ 320.00
FS-108F-POE Overview
FS-108F-POE is a FORTINET enterprise network switch listed by YYST Global for campus switching, data center expansion, spare replacement and network refresh projects. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: FS-108F-POE-Fortinet Network 8xGE RJ45 + 2 SFP Access Switch. Category: Fortinet FortiSwitch 100 Series Entry Switches. Condition: New Factory Sealed.
FS-108F-POE Specification
FORTISWITCH 108F | FORTISWITCH 108F-POE | FORTISWITCH 108F-FPOE | |
|---|---|---|---|
| Hardware Specifications | |||
Total Network Interfaces | 7x GE RJ45, 1x GE/POE-PD RJ45, and 2x GE SFP | 8x GE RJ45 and 2x GE SFP | 8x GE RJ45 and 2x GE SFP |
Dedicated Management 10/100 Port | 0 | 0 | 0 |
RJ-45 Serial Console Port | 1 | 1 | 1 |
Form Factor | Desktop | Deskop / 19” rack bracket | Deskop / 19” rack bracket |
Power over Ethernet (PoE) Ports | 0 | 8 (802.3af/at) | 8 (802.3af/at) |
PoE Power Budget | 0 | 65 W | 130 W |
Mean Time Between Failures | > 10 years | > 10 years | > 10 years |
System Specifications | |||
Switching Capacity (Duplex) | 20 Gbps | 20 Gbps | 20 Gbps |
Packets Per Second (Duplex) | 30 Mpps | 30 Mpps | 30 Mpps |
MAC Address Storage | 8 K | 8 K | 8 K |
Network Latency | 4 μs | 4 μs | 4 μs |
VLANs Supported | 4 K | 4 K | 4 K |
Link Aggregation Group Size | 8 | 8 | 8 |
8 | 8 | 8 | |
Packet Buffers | 512 KB | 512 KB | 512 KB |
DRAM | 256 MB DDR3 | 256 MB DDR3 | 256 MB DDR3 |
FLASH | 32 MB | 32 MB | 32 MB |
768 | 768 | 768 | |
Spanning Tree Instances | 16 | 16 | 16 |
Dimensions | |||
Height x Depth x Width (inches) | 1.18 x 4.72 x 7.09 | 1.73 x 8.23 x 9.85 | 1.73 x 8.23 x 9.85 |
Height x Depth x Width (mm) | 30 x 120 x 180 | 44 x 209 x 250 | 44 x 209 x 250 |
Weight | 1.36 lbs (0.62 kg) | 3.75 lbs (1.70 kg) | 4.05 lbs (1.84 kg) |
Environment | |||
Power Required | 100–240V AC, 50/60 Hz / PoE-PSE(af) | 100–240V AC, 50/60 Hz | 100–240V AC, 50/60 Hz |
Power Supply | 12V/1A DC power adapter included, PoE-PD Built in | AC built in | AC built in |
Redundant Power | No | No | No |
Power Consumption | 6.2 W | 74.4 W | 139.2 W |
21.142 BTU/h | 34.12 BTU/h | 34.56 BTU/h | |
Operating Temperature | 32–113°F (0–45°C) | 32–113°F (0–45°C) | 32–113°F (0–45°C) |
Storage Temperature | -49–158°F (-40–70°C) | -40–158°F (-40–70°C) | -40–158°F (-40–70°C) |
Humidity | 5–95% non-condensing | 5–95% non-condensing | 5–95% non-condensing |
Air-Flow Direction | side-to-back | side-to-back | side-to-back |
Certification and Compliance | |||
FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2 | |||
FS-108F-POE Ordering Information
This listing is an accessory or component and may not include the main device. Confirm the supported platform, connector or form factor, included quantity, hardware revision and required mounting or installation parts before ordering.
FS-108F-POE FAQ
What is FS-108F-POE used for?
FS-108F-POE-Fortinet Network 8xGE RJ45 + 2 SFP Access Switch is a FORTINET accessory or component in the Fortinet FortiSwitch 100 Series Entry Switches category. It may require a compatible main device and should not be treated as a complete standalone system.
Which products are compatible with FS-108F-POE?
Compatibility depends on the exact parent platform, chassis or device revision. Provide the installed model and required quantity so YYST Global can check fit before ordering.
What is included with FS-108F-POE?
Confirm whether the quotation includes only the named component or also includes cables, brackets, optics, licenses or installation hardware. Package contents vary by part number and condition.
What is the price of FS-108F-POE?
The current reference price for FS-108F-POE is US$ 320.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
