FORTINET FortiWiFi-81F-2R-3G4G-PoE FortiGate/FortiWiFi 80F Series
![FWF-81F-2R-3G4G-PoE-[RC] FortiWiFi 81F PoE+ NGFW with LTE & 128GB SSD](/_nuxt/img/contact.ea1c09b.png)
- 763 412 7282
- +86 010 69614620
FortiWiFi-81F-2R-3G4G-PoE Buying Guide
FWF-81F-2R-3G4G-PoE-[RC] FortiWiFi 81F PoE+ NGFW with LTE & 128GB SSD is listed by YYST Global for buyers looking for FORTINET FortiGate/FortiWiFi 80F Series. FortiWiFi-81F-2R-3G4G-PoE FORTINET security firewall appliance. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 9,999.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: FortiWiFi-81F-2R-3G4G-PoE
- Brand: FORTINET
- Category: FortiGate/FortiWiFi 80F Series
- Condition: New Factory Sealed
- Reference price: US$ 9,999.00
FortiWiFi-81F-2R-3G4G-PoE Overview
FortiWiFi-81F-2R-3G4G-PoE is a FORTINET security firewall appliance listed by YYST Global for perimeter security refreshes, HA replacement, branch protection and security appliance sourcing. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: FWF-81F-2R-3G4G-PoE-[RC] FortiWiFi 81F PoE+ NGFW with LTE & 128GB SSD. Category: FortiGate/FortiWiFi 80F Series. Condition: New Factory Sealed.
FortiWiFi-81F-2R-3G4G-PoE Specification
| Exact model | FWF-81F-2R-3G4G-POE |
| Product role | FortiWiFi next-generation firewall with integrated wireless, LTE and PoE |
| IPS throughput | 1.4 Gbps |
| NGFW throughput | 1 Gbps |
| Threat protection throughput | 900 Mbps |
| Wireless and WAN variant | Integrated WiFi and 3G/4G LTE variant |
| PoE | PoE-capable model; confirm port allocation and power budget |
| Onboard storage | 128 GB SSD |
| Performance note | Official performance values are up to values and vary by configuration and enabled security services |
| Official manufacturer reference | FortiGate/FortiWiFi 80F Series official Fortinet Datasheet |
| Procurement validation | Confirm exact SKU, regional variant, licenses, accessories, power option, warranty, condition and lead time before purchase |
| GE RJ45/SFP Shared Media Pairs | 2 |
| GE RJ45 PoE/+ Ports | 6 |
| GE RJ45 PoE/+ FortiLink Ports (Default) | 2 |
| USB Ports 3.0 | 1 |
| Console (RJ45) Port | 1 |
| Internal Storage | 128 GB SSD |
| Trusted Platform Module (TPM) | Yes |
| Bluetooth Low Energy (BLE) | Yes |
| Signed Firmware Hardware Switch | No |
| Antenna Ports (SMA) | 6 |
| Wireless Interface | Dual WiFi Radio, 802.11a/b/g/n/ac/ax + 1 Scanning Radio |
| Multiple User (MU) MIMO | 3 x 3 |
| Maximum Wi-Fi Speeds | 1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz |
| Maximum Tx Power (Wi-Fi) | 20 dBm |
| Antenna Gain | 3.5 dBi @ 5 GHz, 5 dBi @ 2.4 GHz |
| Total Available PoE Power Budget | 96 W |
| Regions Supported | All Regions |
| 3G/4G/LTE Modem Basic Info | 3G4G / LTE |
| Modem Model | Sierra Wireless EM7565(2 SIM Slots, Active/Passive) |
| SIM Slots (Nano SIM) | 2 (Active/Passive mode) |
| LTE Category | CAT-12 |
| Peak Data Rate (LTE) | Download: 600 Mbps, Upload: 150 Mbps |
| Maximum Tx Power (Cellular) | 20 dBm |
| Supported LTE Bands | B1, B2, B3, B4, B5, B7, B8, B9, B12, B13, B18, B19, B20, B26, B28, B29, B30, B32, B41, B42, B43, B46, B48, B66 |
| Supported UMTS/HSPA+ Bands | B1, B2, B4, B5, B6, B8, B9, B19 |
| Modem Features | MIMO GNSS Bias Module Certifications |
| Supported Regions | All Regions |
| Cellular Module Certifications | FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| IPS Throughput | 1.4 Gbps |
| NGFW Throughput | 1 Gbps |
| Threat Protection Throughput | 900 Mbps |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) | 10 / 10 / 7 Gbps |
| Firewall Latency (64 byte UDP packets) | 3.23 μs |
| Firewall Throughput (Packets Per Second) | 10.5 Mpps |
| Concurrent Sessions (TCP) | 1.5 Million |
| New Sessions/Second (TCP) | 45,000 |
| Firewall Policies | 5,000 |
| IPsec VPN Throughput (512 byte) | 6.5 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 2500 |
| SSL-VPN Throughput | 950 Mbps |
| Concurrent SSL-VPN Users (Tunnel Mode, Recommended Max) | 200 |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 715 Mbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 700 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 100,000 |
| Application Control Throughput (HTTP 64K) | 1.8 Gbps |
| CAPWAP Throughput (HTTP 64K) | 9 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiSwitches Supported | 24 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 96 / 48 |
| Maximum Number of FortiTokens | 500 |
| High Availability Configurations | Active-Active, Active-Passive, Clustering |
| Height x Width x Length (inches) | 2.4 x 8.5 x 7.0 |
| Height x Width x Length (mm) | 60 x 216 x 178 |
| Weight | 3.5 lbs (1.6 kg) |
| Form Factor | Desktop / Wall Mount |
| Input Rating | 54V DC, 2.78A |
| Power Required | Powered by up to two external DC power adapters, 100–240V AC, 50/60 Hz |
| Maximum AC Current | 115Vac/0.9A, 230Vac/0.6A |
| Power Consumption (Average / Maximum) | 109.3 W / 133.6 W |
| Heat Dissipation | 455.6 BTU/h |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 20%–90% non-condensing |
| Noise Level | 31.56 dBA |
| Operating Altitude | Up to 7400 ft (2250 m) |
| Regulatory Compliance | FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| Certifications | USGv6/IPv6 |
FortiWiFi-81F-2R-3G4G-PoE Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | 100% Money Back Guarantee |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
FortiWiFi-81F-2R-3G4G-PoE FAQ
What is FortiWiFi-81F-2R-3G4G-PoE?
FWF-81F-2R-3G4G-PoE-[RC] FortiWiFi 81F PoE+ NGFW with LTE & 128GB SSD is a FORTINET FortiGate/FortiWiFi 80F Series product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the exact model of FortiWiFi-81F-2R-3G4G-PoE?
The listed exact model for FortiWiFi-81F-2R-3G4G-PoE is FWF-81F-2R-3G4G-POE. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the product role of FortiWiFi-81F-2R-3G4G-PoE?
The listed product role for FortiWiFi-81F-2R-3G4G-PoE is FortiWiFi next-generation firewall with integrated wireless, LTE and PoE. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is FortiWiFi-81F-2R-3G4G-PoE available from YYST Global?
YYST Global can help check availability, lead time and configuration for FortiWiFi-81F-2R-3G4G-PoE. Contact the sales team before ordering to confirm current stock.
What is the price of FortiWiFi-81F-2R-3G4G-PoE?
The current reference price for FortiWiFi-81F-2R-3G4G-PoE is US$ 9,999.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
