FORTINET FG-7121F-2 FortiGate 7000F Series
- 763 412 7282
- +86 010 69614620
FG-7121F-2 Buying Guide
FG-7121F-2 FortiGate 7121 16RU High-Density AC Chassis Firewall is listed by YYST Global for buyers looking for FORTINET FortiGate 7000F Series. FG-7121F-2 FORTINET security firewall appliance for security refresh projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 2,150.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: FG-7121F-2
- Brand: FORTINET
- Category: FortiGate 7000F Series
- Condition: New Factory Sealed
- Reference price: US$ 2,150.00
FG-7121F-2 Overview
FG-7121F-2 is a FORTINET security firewall appliance listed by YYST Global for perimeter security refreshes, HA replacement, branch protection and security appliance sourcing. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: FG-7121F-2 FortiGate 7121 16RU High-Density AC Chassis Firewall. Category: FortiGate 7000F Series. Condition: New Factory Sealed.
FG-7121F-2 Specification
| Datasheet series | Fortinet FortiGate 7121F Series |
| Exact model | FG-7121F-2 |
| Security appliance type | FortiGate next-generation firewall appliance |
| Sizing check | Validate firewall, IPS, NGFW, threat protection and VPN throughput against the official datasheet before order |
| Interface check | Confirm RJ45/SFP/SFP+ port count, bypass port requirement and WAN redundancy before purchase |
| Subscription check | Confirm FortiGuard, support term, firmware requirement and HA pair compatibility |
| Procurement validation | Confirm exact part number, condition, licenses, accessories, power/airflow option, warranty, stock and lead time before purchase |
| Official datasheet | Fortinet FortiGate official hardware documentation |
| Hardware Accelerated 400 GE QSFP-DD / 100 GE QSFP28 / 40 GE QSFP+ Slots | 24 |
| Hardware Accelerated 100 GE QSFP28 / 40 GE QSFP+ Slots | 56 |
| Hardware Accelerated 100 GE QSFP28 / 40 GE QSFP+ Management/HA Slots | 4 |
| Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ Slots | 80 |
| Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ SFP Management/HA Slots | 4 |
| GE RJ45 Management Ports | 4 |
| USB Ports | 2 |
| Console Ports | 14 |
| Trusted Platform Module (TPM) | Yes |
| Bluetooth Low Energy (BLE) | No |
| Signed Firmware Hardware Switch | No |
| Onboard Storage | 4x 4 TB SSD |
| Included Transceivers | 4x 10 GE SFP+ SR |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP packets) | 1.89 / 1.88 / 1.129 Tbps |
| IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP packets) | 1.89 / 1.88 / 1.129 Tbps |
| Firewall Latency (64 byte, UDP) | 7.50 μs |
| Firewall Throughput (Packet per Second) | 1680 Mpps |
| Concurrent Sessions (TCP) | 1 Billion |
| New Sessions/Sec (TCP) | 9 Million |
| Firewall Policies | 200 000 |
| IPsec VPN Throughput (512 byte) | 630 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 40 000 |
| Client-to-Gateway IPsec VPN Tunnels | 260 000 |
| SSL-VPN Throughput | 13.7 Gbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 30 000 |
| IPS Throughput (Enterprise Mix) | 675 Gbps |
| NGFW Throughput | 550 Gbps |
| Threat Protection Throughput | 520 Gbps |
| SSL Inspection Throughput | 540 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 480 000 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 100 Million |
| Application Control Throughput (HTTP 64K) | 1.5 Tbps |
| CAPWAP Throughput | N.A. |
| Virtual Domains (Default / Maximum) | 10 / 500 |
| Maximum Number of FortiSwitches Supported | 300 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | N.A. |
| Maximum Number of FortiTokens | 20 000 |
| High Availability Configurations | Active-Active (FGSP), Active-Passive, Clustering |
| Height x Width x Length (inches) | 28.63 x 17.33 x 26.6 |
| Height x Width x Length (mm) | 727.2 x 440 x 675.5 |
| Weight (maximum) | 447.36 lbs (203.1 kg) |
| Form Factor (supports EIA/non-EIA standards) | 16 RU 10 FPM Slots + 2 FIM Slots, default 2xFPM-7620F + 2xFIM-7941F, 19-inch rack mount |
| Power Supply Efficiency Rating | 80Plus Compliant |
| Power Required | 200 to 277 VAC (50/60 Hz) |
| AC Current (Maximum) | 8 x 10A |
| Power Consumption (Average / Maximum) | 8350 W / 9820 W |
| Heat Dissipation (Maximum) | 33 480 BTU/h |
| Redundant Power Supplies | 8 Hot Swappable 2000W AC PSU |
| Fan Tray | Hot Swappable Fan Modules |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 5% to 90% non-condensing |
| Compliance | FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| Certifications | USGv6/IPv6 |
| Special Remarks | Performance based on full 10 FPM loaded configuration; factory fitted with high-density FIM-7941F wide port I/O modules |
FG-7121F-2 Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | 100% Money Back Guarantee |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
Document/Firmware Download
FG-7121F-2 FAQ
What is FG-7121F-2?
FG-7121F-2 FortiGate 7121 16RU High-Density AC Chassis Firewall is a FORTINET FortiGate 7000F Series product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the datasheet series of FG-7121F-2?
The listed datasheet series for FG-7121F-2 is Fortinet FortiGate 7121F Series. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the exact model of FG-7121F-2?
The listed exact model for FG-7121F-2 is FG-7121F-2. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is FG-7121F-2 available from YYST Global?
YYST Global can help check availability, lead time and configuration for FG-7121F-2. Contact the sales team before ordering to confirm current stock.
What is the price of FG-7121F-2?
The current reference price for FG-7121F-2 is US$ 2,150.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
