FORTINET FG-70Gl FortiGate/FortiWiFi 70G Series
- 763 412 7282
- +86 010 69614620
FG-70Gl Buying Guide
FG-70G FortiGate 70G Desktop Next-Generation Firewall is listed by YYST Global for buyers looking for FORTINET FortiGate/FortiWiFi 70G Series. FG-70Gl FORTINET security firewall appliance for security refresh projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 580.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: FG-70Gl
- Brand: FORTINET
- Category: FortiGate/FortiWiFi 70G Series
- Condition: New Factory Sealed
- Reference price: US$ 580.00
FG-70Gl Overview
FG-70Gl is a FORTINET security firewall appliance listed by YYST Global for perimeter security refreshes, HA replacement, branch protection and security appliance sourcing. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: FG-70G FortiGate 70G Desktop Next-Generation Firewall. Category: FortiGate/FortiWiFi 70G Series. Condition: New Factory Sealed.
FG-70Gl Specification
| Datasheet series | Fortinet FortiGate 70G Series |
| Exact model | FG-70GL |
| Security appliance type | FortiGate next-generation firewall appliance |
| Sizing check | Validate firewall, IPS, NGFW, threat protection and VPN throughput against the official datasheet before order |
| Interface check | Confirm RJ45/SFP/SFP+ port count, bypass port requirement and WAN redundancy before purchase |
| Subscription check | Confirm FortiGuard, support term, firmware requirement and HA pair compatibility |
| Procurement validation | Confirm exact part number, condition, licenses, accessories, power/airflow option, warranty, stock and lead time before purchase |
| Official datasheet | Fortinet FortiGate official hardware documentation |
| Hardware Accelerated GE WAN Ports | 2 |
| Hardware Accelerated GE RJ45 Ports | 6 |
| Hardware Accelerated GE RJ45 FortiLink Ports (Default) | 2 |
| USB Port | 1 |
| Console Port (RJ45) | 1 |
| Trusted Platform Module (TPM) | Yes |
| Bluetooth Low Energy (BLE) | Yes |
| Signed Firmware Hardware Switch | Yes |
| IPS Throughput | 2.5 Gbps |
| NGFW Throughput | 1.5 Gbps |
| Threat Protection Throughput | 1.3 Gbps |
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 10 / 10 / 10 Gbps |
| Firewall Latency (64 byte UDP packets) | 2.46 μs |
| Firewall Throughput (Packets Per Second) | 15 Mpps |
| Concurrent Sessions (TCP) | 1.4 M |
| New Sessions/Second (TCP) | 100 000 |
| Firewall Policies | 5000 |
| IPsec VPN Throughput (512 byte) | 7.1 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 500 |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 1.4 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 715 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 140 000 |
| Application Control Throughput (HTTP 64K) | 3.6 Gbps |
| CAPWAP Throughput (HTTP 64K) | 6.8 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiSwitches Supported | 24 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 96 / 48 |
| Maximum Number of FortiTokens | 500 |
| High Availability Configurations | Active-Active, Active-Passive, Clustering |
| Height x Width x Length (inches) | 1.6 x 8.5 x 6.3 |
| Height x Width x Length (mm) | 40.5 x 216 x 160 |
| Weight | 2.01 lbs (0.91 kg) |
| Form Factor | Desktop |
| Input Rating | 12V DC, 3A |
| Power Supply Efficiency Rating | 80Plus Compliant |
| Maximum Current | 100V/0.4A ,240V/0.2A |
| Power Required | Powered by External DC Power Adapter, 100–240V AC, 50/60 Hz |
| Power Consumption (Average / Maximum) | 12.3 W / 12.8 W |
| Heat Dissipation | 43.65 BTU/hr |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 10% to 90% non-condensing |
| Noise Level | Fanless |
| Operating Altitude | Up to 10 000 ft (3048 m) |
| Compliance | FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| Certifications | USGv6/IPv6 |
FG-70Gl Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | 100% Money Back Guarantee |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
Document/Firmware Download
FG-70Gl FAQ
What is FG-70Gl?
FG-70G FortiGate 70G Desktop Next-Generation Firewall is a FORTINET FortiGate/FortiWiFi 70G Series product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the datasheet series of FG-70Gl?
The listed datasheet series for FG-70Gl is Fortinet FortiGate 70G Series. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the exact model of FG-70Gl?
The listed exact model for FG-70Gl is FG-70GL. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is FG-70Gl available from YYST Global?
YYST Global can help check availability, lead time and configuration for FG-70Gl. Contact the sales team before ordering to confirm current stock.
What is the price of FG-70Gl?
The current reference price for FG-70Gl is US$ 580.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
