FORTINET FG-100E FortiGate 100E Series
- 763 412 7282
- +86 010 69614620
FG-100E Buying Guide
FG-100E FortiGate 100E 20-Port RJ45 SD-WAN Next-Generation Firewall is listed by YYST Global for buyers looking for FORTINET FortiGate 100E Series. FG-100E FORTINET security firewall appliance for security refresh projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 1,980.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: FG-100E
- Brand: FORTINET
- Category: FortiGate 100E Series
- Condition: New Factory Sealed
- Reference price: US$ 1,980.00
FG-100E Overview
FG-100E is a FORTINET security firewall appliance listed by YYST Global for perimeter security refreshes, HA replacement, branch protection and security appliance sourcing. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: FG-100E FortiGate 100E 20-Port RJ45 SD-WAN Next-Generation Firewall. Category: FortiGate 100E Series. Condition: New Factory Sealed.
FG-100E Specification
| Datasheet series | Fortinet FortiGate 100E Series |
| Exact model | FG-100E |
| Security appliance type | FortiGate next-generation firewall appliance |
| Sizing check | Validate firewall, IPS, NGFW, threat protection and VPN throughput against the official datasheet before order |
| Interface check | Confirm RJ45/SFP/SFP+ port count, bypass port requirement and WAN redundancy before purchase |
| Subscription check | Confirm FortiGuard, support term, firmware requirement and HA pair compatibility |
| Procurement validation | Confirm exact part number, condition, licenses, accessories, power/airflow option, warranty, stock and lead time before purchase |
| Official datasheet | Fortinet FortiGate official hardware documentation |
| GE RJ45 Ports | 14 |
| GE RJ45 Management/HA/DMZ Ports | 1 / 2 / 1 |
| GE RJ45 WAN Ports | 2 |
| GE RJ45/SFP Shared Media Pairs | 2 |
| USB Port | 1 |
| Console (RJ45) Port | 1 |
| IPS Throughput | 500 Mbps |
| NGFW Throughput | 360 Mbps |
| Threat Protection Throughput | 250 Mbps |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) | 7.4 / 7.4 / 4.4 Gbps |
| Firewall Latency (64 byte UDP packets) | 3 μs |
| Firewall Throughput (Packets Per Second) | 6.6 Mpps |
| Concurrent Sessions (TCP) | 2,000,000 |
| New Sessions/Second (TCP) | 30,000 |
| Firewall Policies | 10,000 |
| IPsec VPN Throughput (512 byte) | 4 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 2,000 |
| Client-to-Gateway IPsec VPN Tunnels | 10,000 |
| SSL-VPN Throughput | 250 Mbps |
| Concurrent SSL-VPN Users (Tunnel Mode, Max Recommended) | 500 |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 130 Mbps |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 125,000 |
| Application Control Throughput (HTTP 64K) | 1 Gbps |
| CAPWAP Throughput (1444 byte, UDP) | 1.5 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiSwitches Supported | 24 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 64 / 32 |
| Maximum Number of FortiTokens | 5,000 |
| Maximum Registered FortiClient | 600 |
| High Availability Configurations | Active-Active, Active-Passive, Clustering |
| Height x Width x Length (inches) | 1.75 x 17 x 10 |
| Height x Width x Length (mm) | 44.45 x 432 x 254 |
| Form Factor | 1U Rack Mount |
| Weight | 7.28 lbs (3.3 kg) |
| Power Input | 100–240V AC, 50/60 Hz |
| Maximum Current | 100V / 0.52A, 240V / 0.22A |
| Power Consumption (Average / Maximum) | 23.0 W / 28.6 W; 51.9 VA |
| Heat Dissipation | 97.6 BTU/h |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 10–90% non-condensing |
| Noise Level | 40.4 dBA |
| Operating Altitude | Up to 7,400 ft (2,250 m) |
| Regulatory Compliance | FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; IPv6 |
FG-100E Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | 100% Money Back Guarantee |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
FG-100E FAQ
What is FG-100E?
FG-100E FortiGate 100E 20-Port RJ45 SD-WAN Next-Generation Firewall is a FORTINET FortiGate 100E Series product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the datasheet series of FG-100E?
The listed datasheet series for FG-100E is Fortinet FortiGate 100E Series. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the exact model of FG-100E?
The listed exact model for FG-100E is FG-100E. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is FG-100E available from YYST Global?
YYST Global can help check availability, lead time and configuration for FG-100E. Contact the sales team before ordering to confirm current stock.
What is the price of FG-100E?
The current reference price for FG-100E is US$ 1,980.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
