V15a+ Buying Guide
V15a+- Contacta Dual Output Hearing Loop Driver is listed by YYST Global for buyers looking for Contacta Contacta. V15a+ Contacta enterprise IT hardware. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 950.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: V15a+
- Brand: Contacta
- Category: Contacta
- Condition: New Factory Sealed
- Reference price: US$ 950.00
V15a+ Overview
V15a+ is a Contacta enterprise IT hardware listed by YYST Global for enterprise hardware procurement, replacement projects and infrastructure expansion. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: V15a+- Contacta Dual Output Hearing Loop Driver. Category: Contacta. Condition: New Factory Sealed.
V15a+ Specification
| Datasheet series | Contacta Assistive Listening Systems |
| Exact model | V15A+ |
| Product role | Assistive listening or speech transfer system; confirm kit configuration, microphone/speaker options and installation requirement |
| Deployment check | Confirm counter/window type, power, loop or speech transfer accessories and compliance requirements |
| Procurement check | Confirm exact kit contents, accessories, condition, warranty and lead time |
| Procurement validation | Confirm exact part number, condition, licenses, accessories, power/airflow option, warranty, stock and lead time before purchase |
| Official datasheet | Contacta official product page |
Physical Data
Dimensions | Height – 42mm (1.65”) Width – 196mm (7.80”) Depth – 132mm (5.20”) [150mm (5.90”) incl. XLR and control dial] |
Weight | 978g (2.15lbs) |
Construction | Mild Steel |
Finish | Black Powder Coated |
Technical Data
Power Supply | 100W 24Vdc 4.17A via External PSU (PS-60) Class 6 External PSU (100V-240V AC 50Hz-60Hz) | |
Inputs | 1 X Balanced Line Level (3 Pin Euro-Block) or 1 X Balanced Line Level (XLR) [optimised for -10dBV to 0dBv] | |
1 X Mic Level (12V phantom power via 680Ω) [optimised for levels above -45dBv] | ||
1 X DC Input | ||
Outputs | 2 X Loop Output (5.08mm Euro-Block) | |
Loop Output Characteristics | Voltage | 15Vrms (42.3Vpk-pk) @ 5Arms (14.14Apk-pk)* |
Current | 5Arms (14.14Apk-pk) up to 300 seconds | |
Loop Connector | 5.08mm Euro-block | |
Audio System | Frequency Response | 80Hz to 9kHz |
Distortion | THD+N <0.3% (-50.5dB) Full current both outputs driven | |
AGC | Peak detecting | |
HF Comp | 7 optimised stages | |
Display & Controls | Display | LED Backlit LCD display |
Control | Single rotary control | |
Fault Monitoring and Protection | Main Display | Open circuit loop (DCR measurement) |
Loop ground fault | ||
Front Panel LED | Output voltage clipping | |
Cooling | Internal heatsinks with thermal protection | |
*Note 1: Z=3Ω (265.4uH + 1.37Ω @ 1.6KHz), Note 2: 1% (-40dB) distortion)
Rear Connections
Warranty:1 year
V15a+ Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | 100% Money Back Guarantee |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
V15a+ FAQ
What is V15a+?
V15a+- Contacta Dual Output Hearing Loop Driver is a Contacta Contacta product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the datasheet series of V15a+?
The listed datasheet series for V15a+ is Contacta Assistive Listening Systems. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the exact model of V15a+?
The listed exact model for V15a+ is V15A+. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is V15a+ available from YYST Global?
YYST Global can help check availability, lead time and configuration for V15a+. Contact the sales team before ordering to confirm current stock.
What is the price of V15a+?
The current reference price for V15a+ is US$ 950.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
Related products
Related V15a+
V15+-Contacta Single Output Hearing Loop Driver
V15+ Contacta enterprise IT hardware. Contact YYST Global for stock, lead time and quote support.
V22- Contacta Single Output Hearing Loop Driver
V22 Contacta enterprise IT hardware. Contact YYST Global for stock, lead time and quote support.
V34a PRO- Contacta Dual Output Hearing Loop Driver
V34a PRO Contacta enterprise IT hardware. Contact YYST Global for stock, lead time and quote support.
STS-SJB-Contacta Break Out Box
STS-SJB Contacta enterprise IT hardware. Contact YYST Global for stock, lead time and quote support.
RF-RX1-865-Contacta Portable Radio Frequency Receiver 865MHz
RF-RX1-865 Contacta enterprise network switch for network refresh projects. Contact YYST Global for stock, lead time and quote support.
RF-RX1-915-Contacta Portable Radio Frequency Receiver 915MHz
RF-RX1-915 Contacta enterprise network switch for network refresh projects. Contact YYST Global for stock, lead time and quote support.
RF-TX1-865-Contacta Portable Radio Frequency Transmitter 865MHz
RF-TX1-865 Contacta enterprise IT hardware. Contact YYST Global for stock, lead time and quote support.
RF-TX1-915-Contacta Portable Radio Frequency Transmitter 915MHz
