CISCO IR809G-LTE-LA-K9 Routers
- 763 412 7282
- +86 010 69614620
IR809G-LTE-LA-K9 Buying Guide
IR809G-LTE-LA-K9 Cisco 809 Industrial Integrated Services Routers is listed by YYST Global for buyers looking for CISCO Routers. IR809G-LTE-LA-K9 CISCO enterprise router for WAN edge projects. Contact YYST Global for stock, lead time and quote support. The listed condition is New Factory Sealed. The reference price is US$ 2,941.00. Contact our sales team to confirm stock, lead time, warranty and configuration before ordering.
- Model: IR809G-LTE-LA-K9
- Brand: CISCO
- Category: Routers
- Condition: New Factory Sealed
- Reference price: US$ 2,941.00
IR809G-LTE-LA-K9 Overview
IR809G-LTE-LA-K9 is a CISCO enterprise router listed by YYST Global for WAN edge routing, branch connectivity, spare replacement and enterprise routing upgrades. This page is intended for buyers comparing replacement parts, project supply, spare inventory and quote options.
YYST Global helps enterprise customers confirm model information, product category, condition, availability and sourcing route before purchase. For time-sensitive projects, send the model number and required quantity so our sales team can check stock, lead time and compatible alternatives.
Product name: IR809G-LTE-LA-K9 Cisco 809 Industrial Integrated Services Routers. Category: Routers. Condition: New Factory Sealed.
IR809G-LTE-LA-K9 Specification
| Datasheet series | Cisco 800 Series Industrial Integrated Services Routers |
| Exact model | IR809G-LTE-LA-K9 |
| Product role | Compact industrial cellular router; confirm LTE region, SIM/carrier support, WAN/LAN interfaces, power input, antennas and IOS license |
| Primary validation | LTE regional variant, cellular bands, antennas and carrier compatibility |
| Procurement check | WAN/LAN interfaces, industrial power input, mounting, IOS license and lifecycle status |
| Procurement validation | Confirm exact part number, condition, licenses, accessories, power/airflow option, warranty, stock and lead time before purchase |
| Official datasheet | Cisco 800 Series Industrial Routers official support documentation |
| Feature | Specification |
| Memory | |
| Default and maximum DRAM | 2 GB |
| Default and maximum flash memory | 4 GB |
| IP rating | IP30 |
| Interface Support | |
| Console | Mini type-B USB; also supports remote 4G LTE diagnostics and monitoring tools |
| WAN interfaces | WWAN with multimode 4G LTE, 3.7G, 3.5G, 3G, and 2G speeds; IR809G-LTE-LA-K9 does not support 2G |
| LAN and WAN interfaces | Two 10/100/1000BASE-T Gigabit Ethernet ports |
| LEDs | System OK (green and amber) |
| WWAN (green) | |
| Speed and link for Gigabit Ethernet WAN port (green) | |
| Speed and link for all Fast Ethernet LAN ports (green) | |
| Serial interface | 1 RS-232 and 1 RS-232/RS-485 |
| Support for asynchronous mode with speed up to 115,200 baud | |
| Serial protocol support | SCADA, DNP3, T101-104, Raw Socket TCP and UDP, and SLIP |
| Physical Characteristics | |
| Physical dimensions (H x W x D) | 1.15 x 5.05 x 6.27 in. (29.21 x 128 x 159.2 mm) |
| Weight | 1 lb 11 oz. (0.77 kg) |
| Mounting options | Panel and door and DIN rail mount |
| Mean time between failure (MTBF; ground benign) | 440,000 hours or more |
| Platform power consumption | Idle = 12W |
| Typical = 15W | |
| Maximum = 19W | |
| Environmental operating temperature range | –40 to 140°F (–40 to 60°C) in a sealed NEMA cabinet with no airflow |
| –40 to 158°F (–40 to 70°C) in a vented cabinet with 40 linear feet per minute (LFM) of air | |
| –40 to 167°F (–40 to 75°C) in a forced air enclosure with 200 LFM of air | |
| Type tested at 85°C for 16 hours | |
| Operating altitude | 50°C up to 5000 ft (above 5000 ft derate maximum operating temperature 1.50°C per 1000 ft) Maximum altitude: 10,000 ft |
| Standard safety certifications | UL 60950-1, 2nd edition |
| CAN/CSA C22.2 No. 60950-1, 2nd edition | |
| EN 60950-1, 2nd edition | |
| CB to IEC 60950-1, 2nd edition with all group differences and national deviations | |
| Hazardous locations standards | ANSI/ISA 12.12.01 (Class 1, Div 2 A-D) |
| CSA 213 (Class 1, Div 2 A-D) | |
| IEC 60079-0 and -15 IECEx test report (Class I, Zone 2, gas groups IIC) | |
| EN 60079-0 and -15 ATEX certification (Class I, Zone 2, gas groups IIC) | |
| Industry standards | IEC 61850-1 |
| IEEE 1613 | |
| EMC emissions | FCC 47 CFR Part 15 Subpart C Class A |
| EN 55032/CISPR 32 Class A, EN 55022 Class A | |
| VCCI Class A, AS/NZS CISPR 32 Class A | |
| CISPR 11 Class A, ICES 003 Class A, CNS 13438 Class A | |
| KN 32 Class A, EN 300 386 | |
| EMC immunity | CISPR 35, EN 55024 |
| KN 35 | |
| EN 61000-4-2, 3, 4, 5, 6, 8, 9, 16, 17, 18, and 29 | |
| Radio cellular | AS/NZS: ACMA EMR, and AS/CA S042.1 and 4 |
| Japan: Articles 2 and 9 | |
| EN 301 489-1, 7, 24, and 52 | |
| EN 301 908 -1, 2, and 13 | |
| EN 301 511 | |
| EN 50385 MPE | |
| FCC 47 CFR Part 22 | |
| FCC 47 CFR Part 15 Subpart C | |
| FCC 47 CFR Part 2 MPE | |
| RSS 102/247 | |
| Power specifications | Minimum and maximum voltage: 9.6 to 60V DC input |
| Maximum and minimum current: 2A (9.6V DC) and 0.4A (60V DC) | |
IR809G-LTE-LA-K9 Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | Free CCIE Expert Technical Support |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
IR809G-LTE-LA-K9 FAQ
What is IR809G-LTE-LA-K9?
IR809G-LTE-LA-K9 Cisco 809 Industrial Integrated Services Routers is a CISCO Routers product supplied by YYST Global for enterprise IT procurement and infrastructure projects.
What is the datasheet series of IR809G-LTE-LA-K9?
The listed datasheet series for IR809G-LTE-LA-K9 is Cisco 800 Series Industrial Integrated Services Routers. Confirm the exact SKU and hardware revision against the project requirement before ordering.
What is the exact model of IR809G-LTE-LA-K9?
The listed exact model for IR809G-LTE-LA-K9 is IR809G-LTE-LA-K9. Confirm the exact SKU and hardware revision against the project requirement before ordering.
Is IR809G-LTE-LA-K9 available from YYST Global?
YYST Global can help check availability, lead time and configuration for IR809G-LTE-LA-K9. Contact the sales team before ordering to confirm current stock.
What is the price of IR809G-LTE-LA-K9?
The current reference price for IR809G-LTE-LA-K9 is US$ 2,941.00. Final pricing can change based on stock, quantity, configuration and delivery destination.
